Atdec ceiling projector mount, adjustable drop - Loads up to 33lb - VESA up to 65x200 - 360° projector rotation - Adjustable drop length 15.7in to 35.5in - Quick release mechanism - Adjustable pitch & role - Advanced cable management - All mounting hardw

Economisez 8%
AtdecSKU: PL5-TH-WH-PJ-CM-854A4J-0881493002562-EN
filler

Prix:
Prix réduit$149.99 Prix normal$163.47

Description

Atdec ceiling projector mount, adjustable drop - Loads up to 33lb - VESA up to 65x200 - 360° projector rotation - Adjustable drop length 15.7in to 35.5in - Quick release mechanism - Adjustable pitch & role - Advanced cable management - All mounting hardware included

The TH-WH-PJ-CM telescopic projector mount securely supports your projector on a pole and can be extended up to 35.4in. 360° rotation offers unparalleled versatility when choosing room layout, as well as multiple presentation positions. Angled ceilings are accommodated as the pole can be adjusted by up to 45°. Easy installation and internal cable management make this mount an ideal solution for Pro AV applications.

Features
  • Maximum load up to 33lb
  • Universal mounting hole pattern suits a wide range of projectors
  • Adjustable telescopic pole allows for 19.6in of drop length adjustment
  • Angled ceiling support
  • 360° rotation around pole
  • Quick release mechanism
  • All mounting hardware included
  • 10 years warranty
Limited Warranty 10 Year
Additional Information
    • Fast, easy installation
    • Minimum drop of 400mm (15.7")
    • Maximum drop of 900mm (35.4")
    • Pan adjustment to 20° at projector for ease of use
    • Maximum pitch adjustment of +/- 40°, maximum roll adjustment of +/- 20°
    • Quick release mechanism for easy installation or removal for maintenance purposes
    • Allows projector to be mounted on angled ceilings by providing the pole horizontal adjustment of up to 45 degree
    • Internal cable management
    • 360° Rotation
Application/Usage Projector
Package Contents
  • 1 x Ceiling Mount Assembly
  • 2 x 100mm Extension Brackets
  • 1 x Mounting Plate
  • 2 x 150mm Extension Brackets
  • 2 x 100mm Extension Brackets
  • 2 x 75mm Extension Brackets
  • 2 x 50mm Extension Brackets
  • 1 x Top Ceiling Hanger
  • 1 x Mid Ceiling Hanger
  • 1 x Bottom Ceiling Hanger
  • 1 x Fixing Coupler
  • 4 x M5 x 10mm Socket Button Cap Screw
  • 1 x 6mm Allen Key
  • 4 x Nylon Anchor Plug
  • 4 x 20mm Washer
  • 4 x 10mm Washer
  • 4 x 8mm Washer
  • 4 x M2.5 x 15 Cross Recessed Screws
  • 4 x M3 x 15 Cross Recessed Screws
  • 4 x M3 x 20 Cross Recessed Screws
  • 4 x M4 x 15 Cross Recessed Screws
  • 4 x M4 x 20 Cross Recessed Screws
  • 4 x M4 x 25 Cross Recessed Screws
  • 4 x M5 x 15 Cross Recessed Screws
  • 4 x M5 x 20 Cross Recessed Screws
  • 4 x M5 x 25 Cross Recessed Screws
  • 4 x M6 x 15 Cross Recessed Screws
  • 4 x M6 x 20 Cross Recessed Screws
  • 4 x M6 x 25 Cross Recessed Screws
  • 1 x 3mm Allen Key
  • 4 x 14 Gauge Coach Screw
  • 4 x Large Spacer
  • 4 x Medium Spacer
  • 4 x Small Spacer
  • 8 x Square Nut
  • 4 x Bottom Spacer
  • 8 x M8 Nylon Nut
  • 8 x M8 x 50mm Socket Head Cap Screw
Country of Origin China
Assembly Required Yes
Adjustable Height Yes
Device Supported Projector
Features Cable Management
Swivel
360° Rotation
Pitch Adjustment
Roll Adjustment
Quick Release Mechanism
Maximum Load Capacity 14.97 kg
Material Steel
Color White
Silver
Length 17" (431.80 mm)
Height 4" (101.60 mm)
Width 6" (152.40 mm)
Product Type Ceiling Mount
Manufacturer Part Number TH-WH-PJ-CM
Manufacturer Website Address http://www.atdec.com
Manufacturer Atdec Pty Ltd
Product Model TH-WH-PJ-CM
Product Name TH-WH-PJ-CM Ceiling Pole Projector Mount
Brand Name Atdec
