The Larson Electronics J15254 Explosion Proof Control Station Switchboard offers control of connected devices and machines in flammable facilities. Compatible with 400V AC 50Hz, the 160-amp system contains one main board and two branch boards. This unit is constructed of copper-free aluminum, contains 13 aluminum plugs and is secured on a modular frame with floor mounting brackets.
The J15254 is a durable explosion proof control station designed for combustible ATEX/IECEx rated sites. This unit is rated three phase 400V AC 50 Hz with a power rating of 160 amps. Operators are provided access to one main board and two branch boards on the station. The 63kW 100-amp
4-pole
400V 50Hz main board contains a direct-mounted external front operating handle disconnect. The LBS offers the following types of protection: three phase failure, over/under voltage and phase sequence. A bus bar with a 35kA breaking capacity can be found inside the main switch board.
This flameproof system is equipped with two 80-amp
4-pole
380V 50Hz MCCBs and contains an ultimate breaking capacity (ICU) of 25k. Protective features of the MCCBs include: adjustable short circuit, adjustable overload, earth leakage and on/off indications. External pushbuttons enable operators to switch the circuit breakers on/off. The two branch boards are equipped with eight 16-amp 2-pole 220V 50Hz outgoing MCBs with an ICU of 10kA and two 16-amp 2-pole 220V 50Hz spare MCBs with an ICU of 10kA.
The J15254 is constructed of copper-free aluminum and finished in powder coated window gray (RAL 7040) for durability and aesthetics. This flameproof station comes with internal and external earth components. Equipped with a T6 temperature rating, the unit is IP66 rated, making it suitable for indoor and outdoor use.
Plugs:
This ATEX/IECEx-rated unit contains a total of 13 aluminum plugs: (1) M63x1.5 and (12) M25x1.5. An external M10 earth stud can be found at the base of the control station.
Plugs/Mounting:
All three switch boards are secured on a modular mounting frame for ease of installation. The explosion proof system is compatible with stanchion mounting requirements and features floor mounting brackets.
Applications:
Petroleum refineries, chemical and petrochemical plants, paint spray booths, food manufacturing buildings, agricultural sites, grain storage centers, small motors, manual control and more.
Contact info@purilite.ca for more information about our custom options tailored to meet your specific industry needs.
Specifications
Listing: European Union, International
Unit Type: Explosion Proof Control Station Switchboard
Board Dimensions: 24.9"-H x 17.08"-L x 13.1"-W (634mm x 434mm x 335mm)
Base Dimensions: 59"-H x 23.6"-W (1500mm x 600mm)
Board Quantity: 3
Station Configuration: (1) Main Board, (2) Branch Boards
Weight: -
Rated Voltage: 400V AC 3PH, 50Hz
Rated Power: 160A
Main Board: (1) 63kW 100A 400V 3PH 4P Disconnect LBS
Disconnect Type: External Front Operating Handle
LBS Protection: 3PH Failure, Over/Under Voltage, Phase Sequence
Bus Bar Breaking Capacity: 35kA
Branch Boards: (2) 80A 380V 3PH 50Hz MCCB
MCCB ICU: 25kA
MCCB Protection: Adjustable Short Circuit, Adjustable Over Load, Earth Leakage, On/Off Indications
Circuit Breaker Switch Type: External Pushbutton (On/Off)
Outgoing MCBs: (8) 16A 2P 50Hz [220V]
Spare MCBs: (2) 16A 2P 50Hz [220V]
Outgoing/Spare MCB ICU: 10kA
Earth: Internal/External (M10)
Materials: Copper-free Aluminum (Housing), Aluminum (Plugs)
Finish: Powder Coated
Mount: Stanchion w/ Modular Frame, Floor Mounting Brackets
Plug Quantity: 13
Plug Sizes: (1) M63x1.5, (12) M25x1.5
Color: Window Gray (RAL 7040)
