Larson Explosion Proof Cable Gland - Class I, II, III - Aluminum - NEMA 4X - IP66 - 1/2" NPT Hub

Larson ElectronicsSKU: PL3-CGB-C1D1-ALU-0.5
filler

Price:
Sale price$212.00

Description

Made in the USA
The Larson Electronics CGB-C1D1-MCHL-ALU-0.5 Explosion Proof Cable Gland provides secure and safe cable connections in combustible facilities. This rough service jacket cable gland is constructed of copper-free aluminum and caters to standard 1/2" NPT hubs for connection.
The CGB-C1D1-MCHL-ALU-0.5 is a heavy duty cable gland for flammable and rugged environments. This rough service jacket unit features a standard entry thread of 1/2" NPT and a minimum/maximum cable jacket diameter of 0.5" NPT/0.75" NPT. The ATEX-rated cable gland, which contains a 360° grounding spring (non-magnetic), is waterproof (IP66) and designed for use in environments ranging between -60°C to 85°C.
A liquid pour sealing system is used to seal the accessory. The sealing compound is not included with the cable gland (sold separately).
Applications:
Mechanical cable retention, cable connections, cable fittings, explosive work sites, hazardous locations, instrumentation, telecommunication, cable management and more.
Contact info@purilite.ca for more information about our custom options tailored to meet your specific industry needs.

Specifications
Unit Type: Explosion Proof Cable Gland
Weight: 0.14 lbs
Cable: Rough Service Jacket
Entry Thread (Hub): 1/2" NPT
Minimum Thread Length: 0.78" NPT
Cable Armor Diameter (Stop In): 0.42" NPT (Min) to 0.55" NPT (Max)
Cable Armor Diameter (Stop Out): 0.55" NPT (Min) to 0.63" NPT (Max)
Cable Jacket Diameter: 0.50" NPT (Min) to 0.75" NPT (Max)
Max Over Conductors: 0.51" NPT
Across Flats: 1.20" NPT (Max)
Across Corners: 1.32" NPT (Max)
Nominal Protrusion Length: 2.44" NPT
Operating Temp: -60°C to 85°C
Materials: Copper-free Aluminum
Armor Clamping: 360° Stainless Steel Grounding Spring (Non-magnetic)
Seal: Sold Separately
