10A Explosion Proof Push Control Station - Class I, II, III - (2) Momentary PBs, (1) 2-Pos Switch - Labels

LARSON ELECTRONICSSKU: PL3-EPCS-PB10-2XMPB-2PS-N4X-M1
filler

Price:
Sale price$4,026.99

Description

Specifications / Additional Information
EPCS-PB10-2XMPB-2PS-N4X-M1 Explosion Proof Control Station Ratings/Approvals
Listing: NRTL Listed for United States, Canada Class I, Divisions 1 & 2, Groups C, D
Unit Type: Explosion Proof Push Button Switch Class II, Division 1, Groups E, F & G
Dimensions: 13.08" x 8.14" x 9.82" Class III
Weight: - NEMA 3R, 4, 4X, 7 (C, D), 9 (E, F, G)
Voltage: - NRTL Listed to UL 508A, UL 1203
Push Button Type: (2) Momentary NRTL Listed to CSA C22.2 No 14, 25, 30
Push Button Color/Labels: (1) Green/Open, (1) Red/Closed
PB Contacts (1 Set per Push Button): (1) NO, (1) NC- 10A Rated
Switch Type: 2-position Switch
Switch Label: Local/Remote
Material: Copper Free Aluminum
Mount: Surface
Configuration: Dead End or Feed Through
Hub Size: 1/2" NPT or 3/4" NPT
' Product Overview '
The Larson Electronics EPCS-PB10-2XMPB-2PS-N4X-M1 Explosion Proof Control Station is suitable for use in Class I, II and III rated combustible sites. This weatherproof unit contains three operators: (2) momentary push buttons and (1) 2-position switch. The operators are labeled for proper use. Protected by a copper-free aluminum enclosure, the control device is offered with 1/2" or 3/4" hub size. The EPCS-PB10-2XMPB-2PS-N4X-M1 is recommended for motor or equipment control in flammable facilities. The unit contains two momentary push button switches, which are both equipped with one NO and one NC contacts, rated at 10 amps. The green switch is labeled Open and the red switch is labeled Closed. Operators may access one 2-position switch with a Local/Remote label. The NEMA-rated device is constructed of copper-free aluminum. The EPCS-PB10-2XMPB-2PS-N4X-M1 comes with stainless steel captive screws for the cover assembly. Hubs: The explosion proof device is offered with 1/2" NPT or 3/4" NPT hub size and in dead end or feed through configuration for completing wiring connections. Mount: The EPCS-PB10-2XMPB-2PS-N4X-M1 is compatible with surface mounting applications. Applications: Starters, remote control of motors, chemical processing plants, food processing facilities, oil refineries and other hazardous locations applicable to the unit's classified ratings.
