Larson 15A Explosion Proof Extension Cord - 100' 12/3 SOOW Cord w/ General Area Plug - EXP Connector

Larson ElectronicsSKU: PL3-EPEXC-CO-100-12.3-15A-GAP
filler

Price:
Sale price$1,863.99

Description

PuriLite suggests you place an order directly with us for large Larson orders due to the potential customization requirements. Please call us at 1-844-787-5483 to place your order. If you prefer to place your order online, a PuriLite agent will be in touch with you to discuss any custom options.
Made in the USA
The EPEXC-CO-100-12.3-15A-GAP from Larson Electronics is a 100` Explosion Proof Extension Cord that allows operators to safely extend the range of their explosion proof light or equipment cords beyond the boundaries of the hazardous work area. This explosion proof extension cord is rated for use in Class I Division 1 Groups C & D and Class II Division 1 Groups F & G hazardous areas.
These units are constructed of 100 feet of 12/3 SOOW explosion proof cord rated at 20 amps of continuous service. The cord is chemical and abrasion resistant and comes with an explosion proof, 20 amp
EPCO-20A
receptacle installed on one end and a general area 15 amp plug installed on the other end. The plug on this cord can be used in standard electrical outlets.
**PLEASE NOTE: THE CORD CAP MUST BE PLUGGED IN OUTSIDE OF THE HAZARDOUS AREA AND IS NOT EXPLOSION PROOF**
The plugs on these units are of a twist lock design. In order for a secure and working connection to take place, the operator must insert the plug and twist until it locks into place. This ensures a safe seal is made before any sparks from electrical contact can take place. To ensure the highest safety, operators should make connections outside of the hazardous area.
The receptacle is constructed of non sparking aluminum and finished with an epoxy powder coating for durability and added corrosion resistance. The internal receptacle plug contacts are constructed of brass and designed to maintain constant pressure along their entire length for superior connectivity. The plug receptacle is deeply recessed to prevent accidental contacts and designed for twist lock plug insertion to provide secure connections. A neoprene seal fitted inside the connector receptacle seals against the plug when inserted to provide positive sealing against water ingress. A spring loaded receptacle door provides an automatic weather-tight seal when the plug is removed. This flip-style lid features a special notch, allowing operators to lock the door in the open position while plugging or unplugging devices. With no devices plugged into the connector, the lid will screw shut, providing a NEMA 4X seal. When a plug is installed in this connector, the internal seals provide a NEMA 3 seal.
5-15 Straight Blade Plug
L5-15 Twist Lock Plug
L6-15 Twist Lock Plug
Wiring/Plug:
This explosion proof extension cord is equipped with 100 feet of 12/3 chemical and abrasion resistant SOOW cord that is fitted with an industrial grade cord cap for easy connection to common wall outlets. Plug options include standard 5-15 15 amp straight blade plug for 110V wall outlets with ground, standard 6-15 15 amp straight blade plug for 220-240V wall outlets with ground, NEMA L5-15 15 amp twist lock plug for 125V twist lock outlets and NEMA L6-15 15 amp twist lock plug for 240V twist lock outlets.
The receptacle`s contacts are deep recessed to avoid accidental contact and will accept standard non explosion proof plugs that are NEMA 5-20R, or 6-20R compatible although explosion proof plugs must be used to preserve explosion proof approval in hazardous environments. Ordinary location plugs will NOT activate this cord`s explosion proof receptacles. This explosion proof connector is a mate for the Larson Electronics EPP-15A and EPP-20A explosion proof plugs and is compatible with all the Larson Electronics explosion proof lights we make with an explosion proof plug. This unit`s receptacle is designed to safely contain any arcs between the internal contacts that may be created within the receptacle housing.
Inter-Compatibility:
The included plugs and receptacle are cross-interchangeable with Crouse Hind™ part# ENP5201 plugs and receptacles and Hubble-Killiark part# UGP-20231 ACCEPTOR plugs and receptacles. Any equipment requiring these C-H or H-B plugs should work with these cords. Due to possible manufacturer changes we cannot guarantee interchangeability although we have made every effort to ensure cross compatibility correctness.
Suggested Applications:
Manufacturing, Industrial, Warehouse, Lighting, Explosion Proof Light Fixtures, Grinders, Wet areas or Locations Where Combustible Dust is Present.
Contact info@purilite.ca for more information about our custom options tailored to meet your specific industry needs.

Specifications
Amp Rating: 20 Amp Continuous Service
Dimensions: Cord length-100 Feet Plug-2.78"-L 1.75"-W 3.69"D X 8.25"L
Configuration: 2 Pole 3 Wire 2 Pole 3 Wire
Suitable Plug Cable Diameter: .538" to .639"

Wiring: 100` 12/3 SOOW Cable Terminated w/ (1) General Area 15 Amp Cord Cap and (1) 20 Amp Receptacle
Receptacle Specs: 1 Inline Receptacle
Configuration: 2 Pole 3 Wire 2 Pole 3 Wire
Materials: Copper Free Aluminum
Dimensions: Cord length-100 Feet Plug-2.78"-L 1.75"-W 3.69"D X 8.25"L
Cord Cap Options: 5-15 Straight, 6-15 Straight, L5-15 Twist, L6-15 Twist
Finish: Epoxy Powder Coat
