Larson Explosion Proof 6 Outlet Extension Cord - 20A Continual Service - 50' SOOW Cable - Scaffold Mount

Larson ElectronicsSKU: PL3-EPEXC-JH6X-12.3-50
filler

Price:
Sale price$10,495.99

Description

PuriLite suggests you place an order directly with us for large Larson orders due to the potential customization requirements. Please call us at 1-844-787-5483 to place your order. If you prefer to place your order online, a PuriLite agent will be in touch with you to discuss any custom options.
Made in the USA
The Larson Electronics EPEXC-JH6X-12.3-50 50` Explosion Proof Extension Cord allows operators to safely extend the range of their explosion proof light or equipment cords beyond the boundaries of the hazardous work area. This unit features six outlets for powering 125V or 250V explosion proof equipment. For secure and versatile applications, the device is supported by a scaffold/ladder mounting system.
The EPEXC-JH6X-12.3-50 comes with 50 feet of 12/3 SOOW explosion proof cord and is rated at 20 amps of continuous service. The cord is chemical and abrasion resistant and comes with six, inline 20 amp explosion proof receptacles installed on one end and a standard explosion proof plug installed on the other end. This unit enables multiple connections from a single cord. The EPEXC-JH6X-12.3-50 is mounted on a scaffold/ladder mount, with the outlets located at the center of the backpack component. This mounting system is compatible with railings, scaffoldings or ladders.
Each receptacle`s contacts are deep recessed to avoid accidental contact and will accept standard non explosion proof plugs that are NEMA 5-20R, or 6-20R compatible although explosion proof plugs must be used to preserve explosion proof approval in hazardous environments. Ordinary location plugs will NOT activate this cord`s explosion proof receptacles. The plugs on these units are of a twist lock design. In order for a secure and working connection to take place, the operator must insert the plug and twist until it locks into place. This ensures a safe seal is made before any sparks from electrical contact can take place. To ensure the highest safety, operators should make connections outside of the hazardous area.
We offer this unit in a 125V or 250V configuration. Each receptacle`s contacts are deep recessed to avoid accidental contact and will accept standard non explosion proof plugs that are NEMA 5-20R, or 6-20R compatible although explosion proof plugs must be used to preserve explosion proof approval in hazardous environments. Ordinary location plugs will NOT activate this cord`s explosion proof receptacles.
These explosion proof extension cords are preconfigured in 125V (left) or 250V (right). Each unit is equipped with a 20 amp explosion proof cord cap and rated for 20 amps of continual service. The outlets are a twistlock design. The deep recessed contacts in the receptacle housing prevents ordinary and wet location plugs from activating the explosion proof outlets.
125V 5-20P Explosion Proof Straight Blade Plug
250V 6-20P Explosion Proof Straight Blade Plug
125V 5-15/20 Explosion Proof Outlet
Outlet accepts 15A and 20A Explosion Proof Plugs
Outlet accepts 6-15P and 6-20P Explosion Proof Plugs
Inter-Compatibility:
These cords use T style plugs and will work with non-explosion proof standard receptacles and plugs (NEMA 5-15R, 5-20R, or 6-20R) but will not work with standard 120V wall outlets. The included plugs and receptacles are cross-interchangeable with Crouse Hind™ part# ENP5201 plugs and receptacles and Hubble-Killiark part# UGP-20231 ACCEPTOR plugs and receptacles. Any equipment requiring these C-H or H-B plugs should work with these cords. Due to possible manufacturer changes we cannot guarantee interchangability although we have made every effort to ensure cross compatibility correctness.
Suggested Applications:
Manufacturing, Industrial, Warehouse, Lighting, Explosion Proof Light Fixtures, Grinders, Wet areas or Locations Where Combustible Dust is Present.
Contact info@purilite.ca for more information about our custom options tailored to meet your specific industry needs.

Specifications
Amp Rating: 20 amp Continuous Service

Dimensions: Cord-50 Feet  Plug-2.78"-L 1.75"-W
Configuration: 2 Pole 3 Wire 2 Pole 3 Wire
Suitable Plug Cable Diameter: .538” to .639”

Wiring: 50` 12/3 SOOW Cable Terminated w/ (1) Explosion Proof Straight Blade Plug and (6) 20 Amp Receptacles
Cord Cap: 20 Amp 5-20P (125V) or 20 Amp 6-20P (250V) EXP Plug
Voltage: 125 Volts or 250 Volts
Mounting: Scaffold/Ladder Mount
Receptacle Specs: 6 Inline Receptacles
Configuration: 2 Pole 3 Wire 2 Pole 3 Wire

Materials:  Copper Free Aluminum
Dims:- Single Receptacle- 3"-W X 5.69"-D X6.13"-H
Mating Plugs: ****EPP-15A, EPP-20-A****
Finish: Epoxy Powder Coat
