Explosion Proof Enclosure - 10"x14"x6" Internal Dims - C1D1 - Sight Glass - (2) Push Buttons
Explosion Proof Enclosure - 10"x14"x6" Internal Dims - C1D1 - Sight Glass - (2) Push Buttons
| EPL-AEB-10.14.6-SG-2PB-2X.75S Explosion Proof Enclosure | Ratings |
| External Dimensions: 15.25" x 8.90" x 19.25" | Class I, Divisions 1&2 Groups B,C,D |
| Internal Dimensions: 10€Â-L x 14€Â-W x 6€Â-H | Class I, Zones 1&2 Groups IIB+H2,IIA |
| Pan Dimensions: 9" x 13" | Class II, Divisions 1&2 Groups E,F,G |
| Available Dimensions for Devices: 10" x 14" x 6.20" | Class III |
| Weight: 82 lbs | NEMA 3, 4, 4X |
| Maximum Conduit Size:Â 3" | CENELEC/ATEX/IEC Ex |
| Maximum Operators on Lid: 5 Rows of 3 = 15 | Ex d IIB + H2 T5 or T6 |
| Sight Glass Dimensions: 5" x 9" | Ex tD A21 IP66 |
| Push Buttons: (2) Momentary Push Buttons | Tamb = + 60°C |
| Mounting Leg Height: 0.25" | Â |
| Mounting Dimensions (Horizontal) Height: 4.94" | Â |
| Mounting Dimensions (Horizontal) Width: 8.94" | Â |
| Mounting Dimensions (Vertical) Height: 12.94" | Â |
| Mounting Dimensions (Vertical) Width: 16.94" | Â |
| Cover Type: Bolted | Â |
| Materials: Copper-free Aluminum | Â |
| Mounting: Surface Mount | Â |
| Backplate: N/A | Â |
| Hinges: N/A | Â |
| Total Hubs: 2 | |
| Hub Sizes: (2) 3/4" NPT | |
| Hub Locations: (2) 3/4" NPT @ South Side | Toll Free:Â 1-800-369-6671 |
| Color: Grey | |
| Shipping Dimensions: 48"-L x 48"-W x 27.25"-H | |
| Shipping Weight: 137 lbs | |
| *All grounding shall comply with state and local codes and meet the minimum requirements of the National Electronic Code section 250* |
| The Larson Electronics EPL-AEB-10.14.6-SG-2PB-2X.75S Explosion Proof Enclosure provides operators with a Class I and II, Divisions 1 and 2 copper-free aluminum enclosure designed to hold electrical equipment up to 10" by 14" by 6" in size. Equipped with a sight glass and two push buttons, this NEMA 4X rated explosion proof device is ideal for indoor or outdoor applications where flammable vapors, gases, or dusts exist or stand the potential to exist. *PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO EXPLOSION PROOF ENCLOSURES* The EPL-AEB-10.14.6-SG-2PB-2X.75S explosion proof enclosure is made of copper-free aluminum and includes a watertight gasket for a NEMA 4X protection rating. The internal cavity of this flameproof enclosure measures 10" in length by 14" in width by 6" in height. This unit caters to a maximum of 15 operators on the lid (5 rows of 3 = 15) and a maximum conduit size of 3". Equipped with a bolted cover, the grey explosion proof enclosure is compatible with surface-mount applications. A sight glass located at the top of the lid, measuring 5" x 9", is available for viewing internal components during operation. Two momentary push buttons at the top of the explosion proof enclosure can be used to control the device inside the unit. One button is for resetting, while the other button is for testing. This explosion proof device is designed for Class I, Divisions 1 & 2 (Groups B,C,D); Class I, Zones 1 & 2 (Groups IIB+H2,IIA); Class II, Divisions 1 & 2 (Groups E,F,G) and Class III rated combustible sites. The NEMA 4X rating makes the unit suitable for both indoor and outdoor applications, as well as ensures protection from water, dust, moisture, dirt and external ice formation. A removable backplate for easy mounting of equipment outside of the enclosure can be provided at an additional cost. Hubs: The EPL-AEB-10.14.6-SG-2PB-2X.75S contains a total of two NPT hubs. Two 3/4" NPT hubs are located on the south side of the explosion proof enclosure. Suggested Applications: Manufacturing, Industrial, Warehouse, Lighting Systems, Oil and Gas, Marine Sites, Textile, Food Processing, Chemical Storage, Wet areas or Locations Where Combustible Dust is Present. At Larson Electronics, we can build enclosures to your specifications. Our craftsmen can custom build any lighting system and/or accessories to fit the unique demands of your operation. A commitment to honesty, quality, and dependability has made Larson Electronics a leader in the lighting and electronics business since 1973. If this model does not meet your needs, please contact us at 1-800-369-6671 or . |
