|EPL-AEB-6.6.4-1X2B-4X.75S-4XCG-M1 Explosion Proof Enclosure||Features/Ratings|
|Internal Dimensions: 6"-L x 6"-W x 4"-H||Class I Divisions 1 & 2 Explosion Proof|
|Weight: 40 lb||Class II Divisions 1 & 2 Explosion Proof|
|Cord Grip Cable Range: 0.122" (Min) to 0.343" (Max)||Class II Divisions 1 & 2 Explosion Proof|
|Mounting: Surface Mount|
|Hub Sizes: (1) 2" NPT and (4) 3/4" NPT||Special Orders - Requirements|
|Hub Qty: 5|
|Hub Locations: (1) 2" NPT on Back Side, (4) 3/4" NPT on South Side||Toll Free: 1-800-369-6671|
|Conduit: Operator Provided||Intl: 1-214-616-6180|
|*All grounding shall comply with state and local codes and meet the minimum requirements of the National Electronic Code section 250*|
|Made in the USA The Larson Electronics EPL-AEB-6.6.4-1X2B-4X.75S-4XCG-M1 explosion proof enclosure provides operators with a Class I and II, Divisions 1 and 2 cast aluminum enclosure designed to hold electrical equipment up to 6" by 6" by 4" in size. Factory tapped with six NPT holes (one 2" NPT hub and four 3/4" NPT hubs), this explosion proof enclosure is ideal for indoor or outdoor applications where flammable vapors, gases, or dusts exist or stand the potential to exist. The EPL-AEB-6.6.4-1X2B-4X.75S-4XCG-M1 is shipped with four cord grips for completing connections. *PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO EXPLOSION PROOF ENCLOSURES* The EPL-AEB-6.6.4-1X2B-4X.75S-4XCG-M1 explosion proof enclosure is made of cast aluminum, is equipped with stainless steel hinge and bolts, and includes a watertight gasket for a NEMA 4X protection rating. The internal cavity of this flameproof enclosure measures 6" in length by 6" in width by 4" in height. A removable backplate for easy mounting of equipment outside of the enclosure can be provided at an additional cost. Four NPT hubs are factory tapped to allow conduit entry into the enclosure. The hub sizes and locations are as follows: one 2" on the back side and four 3/4" on the south side. Mounting is provided by four ears, two per side of the enclosure. This explosion proof enclosure comes with four cord grips that have a cable range of 0.122" (Min) to 0.343" (Max).|
