Explosion Proof Enclosure - 6" x 6" x 4" Int. Dims. - C1D1 - (2) 2" Taps - Surface Mount

LARSON ELECTRONICSSKU: PL3-EPL-AEB-6.6.4-2X2NS
filler

Price:
Sale price$4,554.99

Description

Specifications / Additional Information
EPL-AEB-6.6.4-2X2NS Explosion Proof Enclosure Features/Ratings
Internal Dimensions: 6"-L x 6"-W x 4"-H Class I, Division 1 & 2, Explosion Proof
Weight: 40 lbs Class II, Division 1 & 2, Explosion Proof
Mounting: Surface Mount
Hub Sizes: (2) 2" NPT
Hub Qty:2
Hub Locations: (1) 2" NPT on North Side and (1) 2" NPT on South Side Toll Free: 1-800-369-6671
Conduit: Operator Provided Intl: 1-214-616-6180
  Fax: 1-903-498-3364
  E-mail:
*All grounding shall comply with state and local codes and meet the minimum requirements of the National Electronic Code section 250*
' Product Overview '
Made in the USA The Larson Electronics EPL-AEB-6.6.4-2X2NS explosion proof enclosure provides operators with a Class I and II, Division 1 and 2 cast aluminum enclosure designed to hold electrical equipment up to 6" by 6" by 4" in size. Factory tapped with two 2" NPT hubs, this explosion proof enclosure is ideal for indoor or outdoor applications where flammable vapors, gases, or dusts exist or stand the potential to exist. *PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO EXPLOSION PROOF ENCLOSURES* The EPL-AEB-6.6.4-2X2NS explosion proof enclosure is made of cast aluminum, is equipped with stainless steel hinge and bolts, and includes a watertight gasket for a NEMA 4X protection rating. The internal cavity of this flameproof enclosure measures 6" in length by 6" in width by 4" in height. A removable backplate for easy mounting of equipment outside of the enclosure can be provided at an additional cost. Two NPT hubs are factory tapped to allow conduit entry into the enclosure. The hub sizes and locations are as follows: one 2" on the north side and one 2"" on the south side. Mounting is provided by four ears, two per side of the enclosure.
