Explosion Proof Device Box Instrument Enclosure - Class I, II, III - ATEX/IECEX Rated - Blank Cover

LARSON ELECTRONICSSKU: PL3-EPL-AEC-2.75
filler

Price:
Sale price$1,064.00

Description

Specifications / Additional Information
EPL-AEC-2.75 Explosion Proof Device Box Instrument Enclosure Ratings
Listing: United States, Canada, Europe, Asia Class I, Divisions 1&2, Groups B,C,D
Device Type: Explosion Proof Box w/ Cover Class I, Zones 1&2, Groups IIB+H2,IIA
External Box Dimensions (w/o Cover): 4.63" x 4.63" x 4.15" Class II, Divisions 1&2, Groups E,F,G
Internal Dimensions: 3.75" x 3.75" x 2.68" Class III
Cover Diameter: 3.906" Type 3, 4, 4X
Weight: 5.74 lbs ATEX/IEC Ex
Design: Box w/ Blank Cover Ex d IIC T6 or T5
Volume: 45 cubic in. Ex tD A21 IP66 T80°C or T90°C IP66
Material: Copper-free Aluminum Ta = -20°C to +60°C
Enclosure Finish: Electrostatically Applied Powder Epoxy/Polyester Finish
Mounting: Surface Special Orders/Requirements
Maximum Conduit Size: 1.5"
Color: Gray



' Product Overview '
The EPL-AEC-2.75 from Larson Electronics is an Explosion Proof Device Box Instrument Enclosure that houses compact instruments or devices used in hazardous locations, confined spaces and industrial facilities. This unit contains 45 cubic inches of volume and is constructed of copper-free aluminum. The explosion proof enclosure can be used to comply with domestic and international code requirements, while providing protection for operators and nearby workers. The EPL-AEC-2.75 offers protection from explosive hazards and ignitions, dust, harsh weather and rough treatment (tampering). This explosion proof box contains a blank cover and 45 cubic inches of volume. Constructed of copper-free aluminum, two openings on the unit are available for surface mounting applications. The explosion proof device box is compatible with conduit sizes up to 1.5". This unit is rated Type 3, 4 and 4X and designed to withstand the rigors of demanding environmental and operating conditions while remaining robust and easy to use. Applications: Flow measurement devices, temperature monitors, two-wire transmitters, gas detectors, Ph analyzers, pressure gauges, level detectors, H2S monitors, transducers, pressure switches and other compact industrial instruments/devices.
