Explosion Proof Device Box Instrument Enclosure - Class I, II, III - ATEX/IECEX Rated -(4) 1" NPT Hubs
Explosion Proof Device Box Instrument Enclosure - Class I, II, III - ATEX/IECEX Rated -(4) 1" NPT Hubs
| EPL-AEC-7.75-4X1NSEW Explosion Proof Device Box Instrument Enclosure | Ratings |
| Device Type: Explosion Proof Box w/ Cover | Listed for United States, Canada, Europe, Asia |
| External Dimensions: 12.18" x 11" x 11" | Class I, Divisions 1&2, Groups B,C,D |
| Internal Dimensions: 9.5" x 10.5" x 13.56" | Class I, Zones 1&2, Groups IIB+H2,IIA |
| Cover Diameter: 9.63" | Class II, Divisions 1&2, Groups E,F,G |
| Weight: - | Class III |
| Design: Box w/ Blank Cover | Type 3, 4, 4X |
| Volume: 615 cubic in. | ATEX/IEC Ex |
| Material: Copper-free Aluminum | Ex d IIC T6 or T5 |
| Enclosure Finish: Electrostatically Applied Powder Epoxy/Polyester Finish | Ex tD A21 IP66 T80°C or T90°C IP66 |
| Mounting: Surface | Ta = -20°C to +60°C |
| Maximum Conduit Size: 1" | See Drawing for Hub Placements |
| Total Hub Quantity: 4 | |
| Lid (Top) Hubs: 0 | Special Orders - Requirements |
| North Side Hubs: (1) 1" NPT | |
| South Side Hubs: (1) 1" NPT | |
| East Side Hubs: (1) 1" NPT | |
| West Side Hubs: (1) 1" NPT | |
| Color: Gray | |
| The EPL-AEC-7.75-4X1NSEW from Larson Electronics is an Explosion Proof Device Box Instrument Enclosure that houses compact instruments or devices used in hazardous locations, confined spaces and industrial facilities. This unit contains 615 cubic inches of volume and is constructed of copper-free aluminum. Equipped with four 1" NPT Hubs, this explosion proof enclosure can be used to comply with domestic and international code requirements, while providing protection for operators and nearby workers. The EPL-AEC-7.75-4X1NSEW offers protection from explosive hazards and ignitions, dust, harsh weather and rough treatment (tampering). This explosion proof box contains a blank cover and 615 cubic inches of volume. Constructed of copper-free aluminum, four openings at every corner of the unit are available for surface mounting applications. The explosion proof device box is compatible with conduit sizes up to 1". This unit is rated Type 3, 4 and 4X and designed to withstand the rigors of demanding environmental and operating conditions while remaining robust and easy to use. Hubs:The EPL-AEC-7.75-4X1NSEW contains a total of four 1" hubs on the enclosure. There is a single 1" hub on each of the north side, south side, west side, and east side of the enclosure. Applications: Flow measurement devices, temperature monitors, two-wire transmitters, gas detectors, Ph analyzers, pressure gauges, level detectors, H2S monitors, transducers, pressure switches and other compact industrial instruments/devices. |
