Larson 100 ft. Explosion Proof String Lights - Class 1 & 2, Division 1 - 5 Drop Lights - 20ft Spacing

Larson ElectronicsSKU: PL3-EPL-SL-5-20X
filler

Price:
Sale price$9,127.99

Description

PuriLite suggests you place an order directly with us for large Larson orders due to the potential customization requirements. Please call us at 1-844-787-5483 to place your order. If you prefer to place your order online, a PuriLite agent will be in touch with you to discuss any custom options.
Made in the USA
The Larson Electronics EPL-SL-5-20X Explosion Proof String Light set is UL Listed Class 1 Division 1 Groups C and D - and is ideal for general close work and inspection activities in hazardous locations requiring explosion proof protection.
This explosion proof string light set from Larson Electronics contains a total of five, 26 watt, 75 watt or 100 watt work lights depending upon configuration, equipped with aluminum hooks and connected in series along 100 feet of 14/3 SOOW explosion proof cord. A molded T junction is mounted every ten feet, with 3 feet of 16/3 SOOW cord connecting a single drop light to the backbone. The cord on this unit is terminated with a Class 1, Division 1 explosion proof plug for complete protection. With this arrangement, each drop light cannot spark if pulled apart or dragged. A 20 foot tail section of main SOOW cord is included to allow ample length for connection to power sources.
100 Watt Incandescent Bulb
Molded T Connector w/ Hook Ring
10` whip w/ EXP Plug
This unit incorporates ten explosion proof hand lamps connected in series and is suitable for use in areas where petrochemical vapors and various dusts are present. The machined aluminum housings, cast aluminum guard, tempered glass lamp globe, and abrasion resistant cord make this a very durable unit that will resist damage from chemicals, abrasion, vibrations and impacts. This string lighting solution will provide the lighting you require in a flexible, easy to manage configuration. The hand lamps can be moved around and hooked to different points on your scaffold. The lights, however must remain within 20 feet of one other. Each molded T section contains a hook eyelet, allowing operators to suspend the entire backbone off the ground and out of the work space.
5-15 Straight Blade Plug
6-20 Straight Blade Plug
This stringer light set is Class 1, Division 1 rated for Groups C and D with the 100 watt bulb option and Class II, Division 1 Groups F and G with a 60 Watt bulb maximum for compliance to the Class 2 rating. This unit qualifies for both Class 1 Division 1 and Class 2 Division 1 with the optional 26 Watt Compact Fluorescent bulb. Choose your lamp wattage and type below when ordering. This unit can also be ordered in 120VAC, 220VAC or 240VAC configuration for operation with these voltages. A 25` input whip terminated in an explosion proof cord cap completes the explosion proof protection of this string light. Cord cap options include a 5-15 15 amp straight blade plug for use with 120V explosion proof outlets or a 6-20 20 amp straight blade plug for use with 220-240V explosion proof outlets.
Stringer Energy Consumption Comparison
Incandescent
CFL
LED
Wattage
500 watts
130 watts
50 watts
Amp Draw @ 120V AC
4.17 amps
1.09 amps
0.42 amps
Amp Draw @ 277V AC
1.8 amps
0.47 amps
0.18 amps
Amp Draw @ 12V DC
41.67 amps
10.84 amps
4.17 amps
Amp Draw @ 24V DC
20.84 amps
5.42 amps
2.08 amps
Lamp Life Expectancy
1,500 hours
8,000 hours
50,000 hours
Color Temperature
2800K
4300K
6000K
Operation cost per year
$160.6
$41.76
$16.06
Made in USA Quality
Lamp Features
1. Federal Spec Cord.
Up to 500 watts of illumination

Specifications
Listing: United States
Dimensions- Each Lamp: L-16.5"  Diam-5"
Total Watts: 500, 375, or 130 Depending on Lamps
Single Lamp Watt: 26, 75 or 100 watts
Voltage: Stnd-120VAC-60Hz, 220VAC-50Hz, or 240VAC-60Hz
Amps: 4.17 (100W), 3.13 (75W), or 1.09 (26W) @ 120V AC
Mounting: Handheld / Hanging via Aluminum Hooks
Wiring: 100` 14/3 SOOW Cable - 20` between lamps - 10` input whip
Total Length: 100`
Cord Cap: 5-15 or 6-20 Explosion Proof Plug
Single Lamp Weight: 5lbs
Total Weight: 40lbs
