Larson 100 Foot Explosion Proof LED String Light - 5 Hand Lamps - Class 1 & Class 2

Larson ElectronicsSKU: PL3-EPL-SL-5-20X-LED
filler

Price:
Sale price$8,264.99

Description

PuriLite suggests you place an order directly with us for large Larson orders due to the potential customization requirements. Please call us at 1-844-787-5483 to place your order. If you prefer to place your order online, a PuriLite agent will be in touch with you to discuss any custom options.
Made in the USA
The Larson Electronics EPL-SL-5-20X-LED Explosion Proof String Light set is UL Listed Class 1 Division 1 Groups C and D and is ideal for general close work and inspection activities in hazardous locations requiring explosion proof protection.
This explosion proof string light set from Larson Electronics contains a total of five 10 watt work lights equipped with aluminum hooks and connected in series along 100 feet of 12/3 SEOOW explosion proof cord. A molded T junction is mounted every twenty feet, with 3 feet of 14/3 SOOW cord connecting a single drop light to the backbone. The cord on this unit is terminated in a Class 1, Division 1 explosion proof plug for complete protection. With this arrangement, each drop light cannot spark if pulled apart or dragged. A 10 foot tail section of main SOOW cord is included to allow ample length for connection to power sources.
100 Watt Incandescent Bulb
With the EPL-SL-5-20X-LED
Unlike gas burning and arc type lamps that have glass bulbs, LEDs have no filaments or fragile housings to break during operation. Instead of heating a small filament or using a combination of gases to produce light, light emitting diodes (LEDs) use semi-conductive materials that illuminate when electric current applied and emitting light. With LED lights, there is no warm up time or cool down time before re-striking and provide instant illumination when powered on, adding to the reliability of LED technology. By nature, LED light sources run significantly cooler than traditional lamps, reducing the chance of accidental burns and increased temperatures due to heat emissions. This solid state design of light emitting diodes provides a more reliable, stable, durable, and energy efficient light source over traditional lighting.
Safety within the workplace is another benefit of LED work lights and temporary lighting. All light sources produce heat. With traditional work lamps, such as incandescent and halogen light sources, the lamp reaches high surface temperatures. These surface temperatures introduce a burn risk to anyone to anyone that allows prolonged skin contact with the light source, as well as a fire hazard if a flammable material is accidentally set too close to the light source for an extended period of time. While LED fixtures do still produce heat, they are designed with heat sinks to properly disperse the heat. Each LED bulb is engineered to disperse and expel this heat quickly and efficiently, keeping the lamp cooler than traditional light sources. This explosion proof LED work light operates at a lower surface temperature than a comparable model with traditional light source, and thus does not present a significant burn risk if an operator or bystander accidentally brushed up against an exposed lamp, and reduce the fire hazard should they fixture accidentally come in contact with a flammable material for a short period of time. This significantly increases the safety within the work environment.
This unit incorporates ten explosion proof LED hand lamps connected in series and is suitable for use in areas where petrochemical vapors and various dusts are present. The machined aluminum housings, cast aluminum guard, tempered glass lamp globe, and abrasion resistant cord make this a very durable unit that will resist damage from chemicals, abrasion, vibrations and impacts. This string lighting solution will provide the lighting you require in a flexible, easy to manage configuration. The hand lamps can be moved around and hooked to different points on your scaffold. The lights, however must remain within 10 feet of one other. Each molded T section contains a hook eyelet, allowing operators to suspend the entire backbone off the ground and out of the work space.
5-15 Straight Blade Plug
6-20 Straight Blade Plug
This stringer light set is Class 1, Division 1 rated for Groups C and D and Class II, Division 1 Groups F and G. This unit is multi-voltage and configured to operate on 120-277V AC or 11-25V AC/DC, please choose your configuration below. A 10` input whip terminated in an explosion proof cord cap completes the explosion proof protection of this string light. Cord cap options include a 5-15 15 amp straight blade plug for use with 120V explosion proof outlets or a 6-20 20 amp straight blade plug for use with 220-240V explosion proof outlets.
Stringer Energy Consumption Comparison
Incandescent
CFL
LED
Wattage
500 watts
130 watts
50 watts
Amp Draw @ 120V AC
4.17 amps
1.09 amps
0.42 amps
Amp Draw @ 277V AC
1.8 amps
0.47 amps
0.18 amps
Amp Draw @ 12V DC
41.67 amps
10.84 amps
4.17 amps
Amp Draw @ 24V DC
20.84 amps
5.42 amps
2.08 amps
Lamp Life Expectancy
1,500 hours
8,000 hours
50,000 hours
Color Temperature
2800K
4300K
6000K
Operation cost per year
$160.6
$41.76
$16.06
Made in USA Quality
Lamp Features
1. Federal Spec Cord.
5
0 watts of LED illumination

Specifications
Listing: United States
Dimensions- Each Lamp: L-16.5"  Diam-5"
Single Lamp Weight: 6 lbs
Total Weight: 35 lbs
Voltage: 120-277V AC or 11-25V AC/DC
Total Watts: 50
Single Lamp Watt: 10 watts
Total Lumens: 5,250
Single Lamp Lumens: 1,050
Lamp Life: 50,000+ Hours
Luminous Efficacy: 105 Lm/W
Color Temp: 5600K
Amps: 0.42 120V AC
Globe Guard Material: Copper Free Cast Aluminum
Globe Material: Hardened Borosilicate Glass
Handle Material: Rubber
Mounting: Handheld / Hanging via Aluminum Hooks
Handlamp Wiring: 3` 14/3 SEOOW Cable Drop from Backbone
Wiring: 3` 14/3 SEOOW Cable Drop from Backbone 110` 12/3 SEOOW Cable - 20` between lamps - 10` input whip
Cord Cap: 5-15 or 6-20 Explosion Proof Plug
