Explosion Proof Double Gang Switch Kit - Class I, II, III - (2) Momentary 3-way Switches - Copper-free Aluminum - Mounts in Existing Gang Box

LARSON ELECTRONICSSKU: PL3-EPL-SW2-3W-MS-SR-SP0000-KT
filler

Price:
Sale price$1,951.99

Description

Specifications / Additional Information
EPL-SW2-3W-MS-SR-SP0000-KT Explosion Proof Switch Kit - Double Gang Ratings
Listing: NRTL Listed for United States and Canada Class I, Divisions 1 & 2 Groups C, D
Dimensions: 9.38" x 5.88" x 3.44" Class I, Zones 1 & 2 Groups llB, llA
Gang Qty: (2) Class II, Divisions 1 & 2 Groups E, F, G
Weight: - Class III
Voltage Rating: 120-277 V AC, 1-phase NEMA 7 (C, D) 9 (E, F, G)
Current Rating: 20 A
Horsepower: 1 HP @ 120 V, 2 HP @ 240 V
Switch Qty: (2)
Switch Type: Front Lever Operated, Momentary Switches Special Orders - Requirements
Switch Style: 3-way w/ Spring Return to Center Off Position
Padlockable Positions: On or Off
Materials:  Copper-free Aluminum
Installation: Installs in Existing Double Gang Device Boxes
Color: Gray
' Product Overview '
function MM_openBrWindow(theURL,winName,features) { //v2.0 window.open(theURL,winName,features); }
The EPL-SW2-3W-MS-SR-SP0000-KT from Larson Electronics is an Explosion Proof Double Gang Switch Kit that provides a safe and secure method for operators to interrupt power before connecting and disconnecting electrical equipment in hazardous locations. This 20-amp device is compatible with single-phase 120-277 V AC and features two lever switches with momentary action. This kit is designed to be installed in existing double gang device boxes. *Please note that this is for the switch covers and switch operators ONLY. There is NO device box included.* The EPL-SW2-3W-MS-SR-SP0000-KT is used for electrical or circuit switching applications in combustible facilities. This explosion proof unit is rated at 20 amps and operates on single-phase 120-277 V AC. Horsepower ratings include the following: 1 HP @ 120 V and 2 HP @ 240 V. The device is equipped with two front lever operated, momentary switches in a double-gang design. The 3-way switches have a spring return to the center Off position when released. Both On and Off positions can be padlocked for security. The explosion proof switch covers are constructed of copper-free aluminum. Designed for outdoor, rugged and combustible sites, this unit carries NEMA ratings and is suitable for Class I, II and III rated environments. Installation: This unit is designed to be installed in existing double gang device boxes. Suggested Applications: Manufacturing, Industrial, Warehouse, Lighting, Wet areas and Locations Where Combustible Dust is Present.
