Explosion Proof Relay Panel Board - C1D1 - (4) 1/2" NPT Hubs - Stack Lights and Horns

LARSON ELECTRONICSSKU: PL3-EPPB-RWB-8.8.4-4X0.5-MP-M1
filler

Price:
Sale price$8,266.00

Description

Specifications / Additional Information
EPPB-RWB-8.8.4-4X0.5-MP-M1 Explosion Proof Relay Panel Board for Stack Lights and Horns Approvals/Ratings
Listing: NRTL Listed for United States and Canada Class I, Divisions 1 & 2
Internal Dimensions: 8"L x 8"W x 4"H Class II, Divisions 1 & 2
Weight: - NEMA 4X
Input: (4) Sensors
Capacity: (2) Lights and (2) Horns
Mounting: Surface Mount
Hub Sizes: (4) 1/2" NPT
Hub Qty: 4
Hub Locations: (1) 1/2" NPT on East Side, (1) 1/2" NPT on West Side, (1) 1/2" NPT on North Side and (1) 1/2" NPT on South Side
Conduit: Operator Provided
*All grounding shall comply with state and local codes and meet the minimum requirements of the National Electronic Code section 250*
' Product Overview '
Made in the USA The Larson Electronics EPPB-RWB-8.8.4-4X0.5-MP-M1 Explosion Proof Relay Panel Board is recommended for use in Class I and II, Divisions 1 and 2 rated facilities. This unit is specifically designed for operating up to two lights and two horns. Factory tapped with four NPT holes (four 1/2" NPT hubs), this explosion proof device is ideal for indoor or outdoor applications where flammable vapors, gases, or dusts exist or stand the potential to exist. The EPPB-RWB-8.8.4-4X0.5-MP-M1 enables robust control and monitoring of connected lights and horns in combustible sites. The relay panel board accepts a total of four different sensors on the input side. Each sensor is capable of triggering an alarm. When the alarm is triggered, a customer-provided light (usually a lamp on a stack light) and a tone on a customer-provided horn will be activated. The explosion proof relay board handles up to two lights and two horns downstream. This system is made of cast aluminum, is equipped with stainless steel hinge and bolts, and includes a watertight gasket for a NEMA 4X protection rating. The internal cavity measures 8" in length by 8" in width by 4" in height. Hubs: Four NPT hubs are factory tapped to allow conduit entry into the enclosure. The hub sizes and locations are as follows: one 1/2" on the east side, one 1/2" on the west side, one 1/2" on the north side and one 1/2" on the south side. Mount: Mounting is provided by four ears, two per side of the unit.
