10HP Explosion Proof Air Compressor - C1D1 - 480V 3-phase - Air Dryer/50 Gallon Tank - Skid Mount
10HP Explosion Proof Air Compressor - C1D1 - 480V 3-phase - Air Dryer/50 Gallon Tank - Skid Mount
| EXP-ACP-480V.3P-10HP-50G-R2 Explosion Proof Air Compressor | Ratings |
| Unit Type: Rotary Screw Air Compressor | Class I, Division 1 Groups C, D |
| Dimensions: - | Class II, Groups F, G |
| Weight: - |  |
| Voltage: 480V 3-phase |  |
| Amps: - |  |
| HP: 10 |  |
| CFM (Pump): 36.1 CFM |  |
| Max PSI: 150 PSI |  |
| Pump Type: Rotary |  |
| After Cooler: Yes |  |
| Pump Drive: Belt Drive |  |
| Oil Type: Oil Lubricated |  |
| Oil System: Splash Lubricated |  |
| Pump Low Oil Shut Off: No |  |
| Duty Cycle: 100% |  |
| Oil Sight Glass: Yes |  |
| Air Dryer: Yes |  |
| Tank Size: 50 Gallons |  |
| Tank Outlet: 3/4" | |
| Tank Orientation: Horizontal | |
| Operating Temp: +45°C | Toll Free: 1-800-369-6671 |
| Materials: Cast Aluminum, Steel Frame w/ Powder Coat Finish | |
| Mount: Skid Mount w/ Lifting Bar, (2) Eyelets | |
| Wiring: - |
| Made in the USA The Larson Electronics EXP-ACP-480V.3P-10HP-50G-R2 Explosion Proof Air Compressor is designed for Class I, Division 1 and Class II flammable sites and environments. The electric unit features a 10 HP motor which offers 36.1 CFM @ 150 PSI. Constructed of cast aluminum and steel (frame), the unit is compatible with three-phase 480V AC power. The EXP-ACP-480V.3P-10HP-50G-R2 is a powerful, explosion proof air compressor for combustible facilities. This all-electric unit is compatible with three-phase 480V AC power. Equipped with a 10 HP motor, the device has a rotary pump which carries a 36.1 CFM @ 150 PSI rating. The oil/splash lubricated pump features an oil sight glass and after cooler. Operators may access a 50-gallon tank in a horizontal configuration with a 3/4" outlet on the air compressor. An air dryer is included with this explosion proof unit for enhanced and reliable performance. The explosion proof air compressor is constructed of cast aluminum with a powder coat paint finish for durability. Mounting: The EXP-ACP-480V.3P-10HP-50G-R2 is a skid-mounted unit for seamless transportation around the work site. Equipped with a heavy-duty steel frame, operators are provided access to a lifting bar and dual lifting eyes. Applications: Powering equipment and machines, explosive work sites, oil and gas, industrial, construction and more. |
