Explosion Proof Enclosure for Raspberry Pi - 3" Lens - Class I, II, III - ATEX/IEC - (2) Hubs
Explosion Proof Enclosure for Raspberry Pi - 3" Lens - Class I, II, III - ATEX/IEC - (2) Hubs
| EXP-DBE-RBP-3-GL-BP-2X0.75S Explosion Proof Device Box Instrument Enclosure | Ratings/Approvals |
| Listing: NRTL Listed for United States, Canada, Europe, Asia | Class I, Divisions 1 & 2, Groups B, C, D |
| Device Type: Explosion Proof Raspberry Pi Enclosure | Class I, Zones 1 & 2, Groups IIB+H2, IIA |
| External Dimensions: 6.63" x 5.5" x 5.25" | Class II, Divisions 1 & 2, Groups E, F, G |
| Internal Dimensions: 4.63" x 5.75" x 3.28" | Class III, Divisions 1 & 2 |
| Internal Volume: 105 cu. in. | NEMA Type 3, 4, 4X, 7 (B,C,D), 9 (E,F,G) |
| Lens Opening: 3" | ATEX/IEC Ex |
| Weight: - | Ex d IIC T6 or T5 |
| Compatible Raspberry Pi Models: 4 Model B, 3 Model A+, 3 Model B+, 3 Model B, 2 Model B, 1 Model B+, 1 Model A+, Zero, Zero W | Ex tD A21 IP66 T80°C or T90°C IP66 |
| Material: Copper-free Aluminum | Ta = -20°C to +60°C |
| Enclosure Finish: Electrostatically Applied Powder Epoxy/Polyester Finish | Internal Aluminum Mounting Plate |
| Lens Material: Tempered Soda Lime Glass | Â |
| Mounting: Surface | Â |
| Design: Single Box w/ Lens Cover | Â |
| Total Hub Quantity: 2 | Â |
| North Side Hubs: - | |
| South Side Hubs: - | |
| East Side Hubs: - | |
| West Side Hubs: - | |
| Bottom (Back/Base) Hubs: - | |
| Maximum Conduit Size: 2" |
| The EXP-DBE-RBP-3-GL-BP-2X0.75S from Larson Electronics is an Explosion Proof Enclosure for Raspberry Pi, which allows the device to be used in hazardous locations, confined spaces and industrial facilities. This unit contains a 3" lens opening and is constructed of copper-free aluminum. The explosion proof enclosure may be used to comply with domestic and international code requirements, while providing protection for operators and nearby workers. The EXP-DBE-RBP-3-GL-BP-2X0.75S protects Raspberry Pi computer boards from explosive hazards and ignitions, dust, harsh weather and rough treatment (tampering). This unit is equipped with a 3" lens opening and 105 cubic inches of volume. The spacious enclosure provides room for extension modules to be mounted internally. Compatible Raspberry Pi models include the following: 4 Model B, 3 Model A+, 3 Model B+, 3 Model B, 2 Model B, 1 Model B+, 1 Model A+, Zero or Zero W. Constructed of copper-free aluminum, the ATEX/IECEX-rated enclosure is protected by a tempered soda lime glass lens. This unit is rated NEMA Type 3, 4, 4X, 7 (B,C,D) and 9 (E,F,G) and designed to withstand the rigors of demanding environmental and operating conditions while remaining robust and easy to use. Cast mounting lugs are available for mounting. Hubs: This enclosure contains two conduit hubs, which can be used to pass input and output cables during installation. The explosion proof device box is compatible with conduit sizes up to 2". Applications: Raspberry Pi, hazardous locations, industrial sites, automation, remote control, PLCs, Modbus, manufacturing, processing, networks and more. |
