Explosion Proof Digital Countdown Timer - Class I, II, III - 120V, 50/60Hz - LCD Display - Magnetic Switches - NEMA


Sale price$2,804.99


Specifications / Additional Information
EXP-EL-CDT.D-M1-120V Explosion Proof Countdown Timer Ratings/Approvals
Listing: NRTL Listed for United States, Canada Class I, Divisions 1 & 2, Groups B, C, D
Device Type: Explosion Proof Digital Countdown Timer Class II, Divisions 1 & 2, Groups E, F ,G
Dimensions: 4-17/32"H x 6-1/8"W Class III, Divisions 1 & 2
Lens Opening: 2-9/32" NRTL Listed to UL 508A
Weight: - NRTL Listed to UL 1203
Voltage: 120 V AC, 50/60 Hz NRTL Listed to CSA C22.2 No. 14
Clock Display Type: LCD NRTL Listed to CSA C22.2 No. 25
Controls: (4) Magnetic Switches (Hour Settings, Start, Stop, Pause) NRTL Listed to CSA C22.2 No. 30
Auxiliary Contacts: Yes; Normally Open (Contacts Close When Timer Is Started) NEMA 3, 4, 7(B,C,D), 9(E,F,G)
Cover Material: Copper-free Aluminum Alloy
Hour Range: 1 - 3600 Hours
Sealing Gasket: Neoprene O-ring Special Orders - Requirements
Ground Screw Material: Zinc Plated Steel w/ Green Dye
Allen Head Cover Screw Material: Cadmium Plated Steel
Enclosure Finish: Silver Powder Epoxy Paint, Electrostatically Applied
Glass Lens Material: 3/8" Thick Tempered Glass
Wiring Hubs: Offset Feed-thru (3/4" NPT)
' Product Overview '
The EXP-EL-CDT.D-M1-120V from Larson Electronics is an Explosion Proof Digital Countdown Timer that is suitable for use in hazardous locations, confined spaces and industrial facilities. This NEMA-rated unit is compatible with 120 V AC, 50/60 Hz. Magnetic switches enable operators to set the amount of hours without opening the enclosure after installation. The EXP-EL-CDT.D-M1-120V is designed for Class I, II and III rated combustible sites. Equipped with an LCD display, the device contains magnetic switches that allow operators to change the hour settings after installation without opening the enclosure. This feature works through the glass of the clock, enabling operators to change the time settings quickly and safely. Time adjustments with the magnetic switches can be completed in the field (hazardous area). This unit also features buttons for start, stop, and pause which are also controlled by magnetic switches. The timer is protected by a copper-free aluminum housing for durability. Neoprene 0-rings are provided with the enclosure to ensure water resistance in NEMA 4/IP66 conditions. The EXP-EL-CDT.D-M1-120V can be set for any time between 1 hour and 3600 hours. Once the timer is started, it will count down from the amount of hours chosen to zero. This digital countdown timer is equipped with a set of aux contacts for controlling external equipment such as indicator lights or for sending signals to controllers. These contacts are normally open and will close to complete the circuit once the timer starts. Voltage: This digital countdown timer operates on 120 V AC, 50/60 Hz. The explosion proof timer comes with offset feed-thru conduit openings (3/4" NPT). An internal ground screw is conveniently located away from the mounting components. The enclosure is finished with silver powder epoxy paint (electrostatically applied). The ground screws are made out of zinc plated steel with green dye, while the allen head cover screw is constructed of cadmium plated steel. This unit comes with a 3/8" thick tempered glass lens cover. The explosion proof device is rated NEMA Type 3, 4, 7 (B,C,D) and 9 (E,F,G) and designed to withstand the rigors of demanding environmental and operating conditions while remaining robust and easy to use. Applications: Hazardous locations, oil and gas, chemical plants, wastewater facilities, hydrogen plants, battery storage buildings, and more.
