4HP Explosion Proof Variable Frequency Device - 100-120V AC 1PH Input/Output - 25 Amps

LARSON ELECTRONICSSKU: PL3-EXP-VFD-1P-110.120-4HP-25A-DCM
filler

Price:
Sale price$21,314.00

Description

Specifications / Additional Information
EXP-VFD-1P-110.120-4HP-25A-DCM Explosion Proof Variable Frequency Device Features/Ratings
Unit Type: 1 Phase Input/1 Phase Output Variable Frequency Device Class I, Divisions 1 & 2
Dimensions: 16.38" x 22.38" x 9.06" Class II, Divisions 1 & 2
Weight: - Automatic Voltage Regulation
Input/Output Voltage: 100-120V AC, 1PH PLC Multi-step Speed Control
Output Current: 25 Amps
Input Frequency: 48 to 63 Hz
Output Frequency: 0 to 400 Hz
HP: 4
Motor Control: IC+IGBT Toll Free: 1-800-369-6671
Materials: Copper-free Aluminum
Mounting: Surface
Color: Gray
' Product Overview '
The EXP-VFD-1P-110.120-4HP-25A-DCM from Larson Electronics is an Explosion Proof Single-Phase Input, Single-Phase Output Variable Frequency Drive that is suitable for improving AC motor performance in industrial operations. This unit features single-phase 100-120V AC input/output voltage. The 4HP device supports PLC multi-step speed control. The EXP-VFD-1P-110.120-4HP-25A-DCM offers accurate AC motor control in hazardous locations and industrial facilities. This unit is compatible with single-phase 100-120V AC input/output voltage. Input frequency range includes 48 to 63 Hz and output frequency ranges between 0 to 400 Hz. Designed for steady speed error, fast torque rise and protection from resonance vibrations, the 4HP device provides an output current of 25 amps. This explosion proof VFD is protected by a copper-free aluminum housing. The unit is rated for use in Class I, Divisions 1 & 2 and Class II, Divisions 1 & 2 hazardous locations, making it ideal for indoor or outdoor applications where flammable vapors, gases or dust exist or stand the potential to exist. Mounting: Operators may mount the explosion proof VFD phase converter on compatible surfaces. Applications: Speed control of AC motors, industrial machines, large compressors, energy savings and more within Class I & II, Divisions 1 & 2 hazardous locations.
