Outputs: 1 programmable open collector, 1 analog (open collector or high-speed pulse), 2 relay, 2 analog
Analog Input/Output: 2 Input (0~10V or 0/4~20mA), 2 Output (0/4~20mA or 0~10V)
Communication Terminal: RS485 communication interface, support MODBUS-RTU communication protocol
Overload: 150% @ 60s, 180% @ 10s, 200% @ 3s
Operating Temp: â€“10Â°C to +40Â°C
Max Operating Humidity: 90% (Non-condensing)
Toll Free:Â 1-800-369-6671
The EXP-VFD-1P-220.240-1HP-7A-DCM from Larson Electronics is an Explosion Proof Single-Phase Input, Single-Phase Output Variable Frequency Drive that is suitable for improving AC motor performance in industrial operations. This fan-cooled unit features single phase 220-240V AC input/output voltage comparability. Designed for steady speed error, fast torque rise and protection from resonance vibrations, the explosion proof device provides an output current of 7 amps and an operating frequency range of 0 to 3000 Hz with 1 horsepower.
The EXP-VFD-1P-220.240-1HP-7A-DCM offers accurate AC motor control in flammable work sites and industrial facilities. This 1-HP unit is compatible with single-phase 220-240V AC input/output voltage. Designed for steady speed error, fast torque rise and protection from resonance vibrations, the device provides an output current of 7 amps and an operating frequency range of 0 to 3000 Hz.
The EXP-VFD-1P-220.240-1HP-7A-DCM is designed for indoor applications and operating temperatures ranging between â€“10Â°C to +40Â°C. Rated for use in Class I, Divisions 1 & 2 and Class II, Divisions 1 & 2 hazardous locations, this explosion proof VFD is ideal for indoor or outdoor applications where flammable vapors, gases, or dusts exist or stand the potential to exist.
Mounting: Operators may mount the VFD on compatible surfaces. This device measures 12.00" x 12.00" x 10.00".
Applications: Speed control of AC motors, industrial machines, large compressors, energy savings and more within Class I & II, Divisions 1 & 2 hazardous locations.
