2000 Watt Hazardous Area Portable Light Tower - 2 X 1000 Watt Metal Halide Lights - C1D2 - Crank Up

LARSON ELECTRONICSSKU: PL3-HAL-C-2X1000W
filler

Price:
Sale price$6,872.99

Description

Specifications / Additional Information
HAL-C-2X1000W Hazardous Location Light Tower U.L. Ratings
Listing: United States Class I, Division 2 Groups A, B, C, D
Dimensions: 7` Collapsed, 15` Extended NRTL Listed to UL Standard 1598 (supersedes UL Standard 57)
Weight: 115 Lbs including tripod NRTL Listed to UL Standard 844
Total Watts: 2000 watts Class I Div. 2 UL Standard 1598A
Voltage: 120 Volts AC, 16.8 amp draw   Max OP Temp 325°C (T1 NEC ID Number)
Coverage: 85,000 square feet Operating temperature 325 degrees C (T3b)
Lamp Life Expectancy: 12,000+ Hours Not Approved For Confined Spaces
Lamp Type: Metal Halide
Total Lumens: 220,000
Mounting: 7` to 15` Extendable Wheeled Quadpod Tower
Wiring: SOOW Cord
U.L Approval:
' Product Overview '
Made in Texas The Larson Electronics HAL-C-2X1000W Wheeled Quadpod Mounted Hazardous Location Light Tower is NRTL Listed Class 1 Division 2 and is rated for use in wet environments. The wheeled quadpod mount and metal halide lamps used with this unit provide operators with excellent power and efficiency coupled with high versatility and ease of use. Two 1000 watt hazardous area metal halide lamps mounted on a two wheeled adjustable quadpod tower gives operators an easily deployable source of powerful light that can be quickly setup and adjusted to effectively illuminate hazardous work areas. This unit contains two metal halide lamps, and is capable of illuminating 85,000 square feet of work space. The metal halide lamps run cooler than halogen lamps, resulting in an easier to handle unit and less heat in the workspace. This unit`s durability, easy deployment, high power and the good color rendering of its metal halide lamps make it ideal for close work and hazardous areas where safety, detail and accuracy are critical.
This hazardous location metal halide tower light is comprised of a removable dual light head assembly mounted atop an adjustable quadpod light tower fabricated from non sparking aluminum. The non sparking, adjustable and collapsible tripod can be extended to twelve feet and collapsed to seven feet via an included hand winch, while wheels mounted to the bottom of the tower enable the operator to tilt the unit back and simply roll the entire assembly to a new location. The explosion proof light fixture bracket can be removed by releasing the hand knob and sliding the lights and mounting bracket off of the tower support while the legs can be collapsed, aiding in deployment, storage and transport. The lamps can be easily adjusted up, down or from side to side and locked into position.
Click Photo to Enlarge
Lamps: This units` lamp assemblies each include a 1000 watt metal halide bulb, internal ballast and aluminum finish reflector in a copper-free cast aluminum housing with a thermoset powder coat finish. The optical assembly includes thermal shock and impact resistant door glass with a pressure-cast copper-free aluminum door frame and heavy duty, high temperature silicone rubber seal. The lamp socket is a specification grade mogul base porcelain unit with heavy gauge brass, a nickel-plated, double lamp-grip screw shell and spring-loaded center contact. The reflectors are a double segment compound parabolic design with Alzak® finish for maximum efficiency. The lens is constructed of thermal shock and impact resistant tempered glass and the housing contains threaded joints lubricated with non-drying lubricant.  The metal halide lamps have no filament and are thus highly resistant to damage from shocks or impacts, greatly reducing the chances of damage should the tower be knocked over, unlike incandescent lamps which may break or shatter. The lamp housings are waterproof, making this unit ideal for use in wet and marine environments. The metal halide lamps provide 26,000 square feet of coverage with good color rendering and object contrast. The lamps are rated at 12,000+ hours of life, providing longer service life than typical halogen lamps. This tower mounted light system operates with 120 VAC and is supplied with 100 foot 16/3 SOOW cords ending in explosion proof straight blade plug.  Suggested Applications: include but are not limited to wastewater treatment plants, refinery tanks, oil and gasoline loading docks, coal pulverizing facilities, munitions storage areas, tunnel projects, utility gas plants, power plant areas, hazardous areas and mining conveyor belts.
Made in the USA Quality Metal Halide Benefits
1. High Efficiency Metal Halide lamps. 2. 1000 Watt Lamps 3. Rugged Die Cast Aluminum Lamp Housing. 4. Shock Resistant Tempered Glass Lens. 5. Copper Free Shell, Covers and Sealed Fittings. 6. Vibration/Impact Resistant Construction. 7. Low Maintenance. 8. Adjustable from 7 to 12 Foot Height. 9. Non Sparking Aluminum Tower 10. UL Listed for Marine Environments. 1. Long lamp life. 2. High efficiency and low amp draw after initial startup. 3. High durability and reliability. 4. High output and very good color rendering. 5. Vibration and shock resistant. 6. Low maintenance.
