Larson 10 Watt LED Flood Work Light - Magnetic Base - Permanent Stainless Steel Mounting Bracket

Larson ElectronicsSKU: PL3-IL-LED-10W-M

Sale price$395.99


The IL-LED-10W-M  LED Light Bar offers high light output from a compact form factor and  with its magnetic base that has 100 lbs of gripping power and two pin Deutsch connecter, is ideal for a wide range of uses including heavy equipment, boating, vehicle, military, law enforcement and industrial manufacturing applications.
This heavy duty and compact 10 Watt LED light produces an 800 lumen output with low voltage and amp draw and operates on 10-30 VDC. With its
30,000 hour service life the IL-LED-10W-M provides operators with a compact and powerful LED lighting solution.
The IL-LED-10W-M LED light bar from Larson Electronics produces 800
lumens of bright light while drawing only 10 watts. The LEDs are arranged in rows and paired with high purity optics to produce a wide 60 degree flood beam.  These LED light bars are IP67 waterproof, sealed against intrusion by dust and dirt and very ruggedly constructed to withstand the most demanding environments, conditions and applications.
This photo shows a long dark street with no illumination but distant suburban lighting.
This image shows the LED10W-9S illuminating the street.
Heat Management:
Heat is the single largest factor in premature LED failure and color shifting. As a result, many manufacturers reduce the output of their LEDs to reduce the amount of heat produced. These LED light bars utilize an extruded aluminum housing that incorporates an advanced heat radiating design which dissipates heat efficiently to produce the maximum amount of power and longevity. The end result is more light and longer LED life with higher average lumen maintenance after 25,000 hours.
Voltage Control:
These units are able to monitor and adjust input current to maintain the correct LED voltage levels regardless of input levels across a specific range. These LED lights can operate on current ranging from 10 to 30VDC without any modifications necessary as a result. This multi-voltage capability makes these units ideal for mobile and stand alone applications such as those found on commercial boats, heavy equipment and vehicles where power systems don’t always operate with 12 volts and external generators, transformers or inverters are impractical.
The IL-LED-10W-M LED light from Larson Electronics also offer IP67 rated construction that is designed to withstand demanding environmental and operating conditions. These units can withstand frigid temperatures, are waterproof to one meter and resist ingress of dust, dirt and humidity. The housing on this unit is formed from cast aluminum and the lenses are unbreakable polycarbonate.
The IL-LED-18-M comes with a
two pin Deutsch connector
16` Cigarette Plug. We also offer 16` Straight Cord, 21` Ring Terminals, and 21` Battery Clamps.
The 100 lbs Gripping power magnet mounting design allows for easy placement and removal. This mounting system includes a power cord with a cigarette plug connector which makes this unit ideal for vehicle and equipment lighting applications where the unit can simply be attached or removed as needed. Please note, the magnetic base on this unit increases the units overall height.
Most Larson Electronics LEDLB, LEDP3W, LEDP10W, and LED10W series LED spotlights and floodlights are terminated with a Deutsch IPD / LADD DT04-2P connector. The mating connector plug is DT06-2S. Most LEDLB and LED10W series lights ship with mating connector as part of a harness or pigtail, depending on the model. Some larger LED lights like the LEDLB-160X2 or LEDLB-200X2 or multiple function LED lights (i.e. high/low beam, modulating, IR/Visible combos) will have different Deutsch connectors.
IL-LED-10W-M 40° Flood Beam

Lamp Type: LED
Dimensions: 2 5/8 "W  2 5/8"-H  2 5/8"-Depth
Watts: 10
Voltage: 10-30 VDC
Lumens: 800
Mounting:  Magnetic Base W/ 100lbs of Gripping Power
LED Life Expectancy: 25,000 hours
Cord lengths/types: 16` Cig Plug, 16` Straight Cord, 21` Ring Terminals, or 21` Battery Clamps

16` Cig Plug, 16` Straight Cord, 21` Ring Terminals, or 21` Battery Clamps Cord lengths/types:

CE Certified
