Larson 10 Watt LED Flood Work Light - Magnetic Base -High Voltage- Permanent Stainless Steel Mounting Brack

Larson ElectronicsSKU: PL3-IL-LED-10W-M-1227

Sale price$746.99


Buy American Compliant
The IL-LED-10W-M-1227  LED Light Bar offers high light output from a compact form factor and  with its magnetic base that has 100 lbs of gripping power and two pin Deutsch connecter DCP AC/DC converter, is ideal for a wide range of uses including heavy equipment, boating, vehicle, military, law enforcement and industrial manufacturing applications.
This heavy duty and compact 10 Watt LED light produces an 800 lumen output with low amp draw and operates on 120-277 VAC. With its
30,000 hour service life the IL-LED-10W-M provides operators with a compact and powerful LED lighting solution.
The IL-LED-10W-M-1227 LED light bar from Larson Electronics produces 800
lumens of bright light while drawing only 10 watts. The LEDs are arranged in rows and paired with high purity optics to produce a wide 60 degree flood beam.  These LED light bars are IP67 waterproof, sealed against intrusion by dust and dirt and very ruggedly constructed to withstand the most demanding environments, conditions and applications. The converter comes with a straight blade plug on the input lead and a two pin Deutsch connector on the output lead, allowing users to simply plug the IL-LED-10W-M-1227 into a typical wall outlet.
This photo shows a long dark street with no illumination but distant suburban lighting.
This image shows the LED10W-9S illuminating the street.
Heat Management:
Heat is the single largest factor in premature LED failure and color shifting. As a result, many manufacturers reduce the output of their LEDs to reduce the amount of heat produced. These LED light bars utilize an extruded aluminum housing that incorporates an advanced heat radiating design which dissipates heat efficiently to produce the maximum amount of power and longevity. The end result is more light and longer LED life with higher average lumen maintenance after 25,000 hours.
Voltage Control:
These units are able to monitor and adjust input current to maintain the correct LED voltage levels regardless of input levels across a specific range. These LED lights can operate on current ranging from 10 to 30VDC without any modifications necessary as a result. This multi-voltage capability makes these units ideal for mobile and stand alone applications such as those found on commercial boats, heavy equipment and vehicles where power systems don’t always operate with 12 volts and external generators, transformers or inverters are impractical.
The IL-LED-10W-M-1227 LED light from Larson Electronics also offer IP67 rated construction that is designed to withstand demanding environmental and operating conditions. These units can withstand frigid temperatures, are waterproof to one meter and resist ingress of dust, dirt and humidity. The housing on this unit is formed from cast aluminum and the lenses are unbreakable polycarbonate.
The 100 lbs Gripping power magnet mounting design allows for easy placement and removal. This mounting system includes a power cord with a cigarette plug connector which makes this unit ideal for vehicle and equipment lighting applications where the unit can simply be attached or removed as needed. Please note, the magnetic base on this unit increases the units overall height.
The IL-LED-10W-M-1227 comes with a  48 watt power converter that provides a safe and effective way for users to tap into and utilize 120-277 Volt AC power sources and convert this current to 12 Volts DC for use with equipment that requires 12 volt electrical power. The converter features an IP64 rated waterproof design, making it suitable for indoor or outdoor use and includes integral short circuit and overload protection that will shut down the unit in case of faults and overloads to protect the unit and connected equipment from damage.
The IL-LED-10W-M-1227 has 20 feet of SOOW Cable between the converter and the IL-LED-10W-M-1227 and 6 feet between the converter and the plug terminals. Measuring 7 inches long by 2.5 inches wide by 1.5 inches deep, the converter weighs less than one pound and is mounted with two conventional screws via slots that allow removal and repositioning simply by loosening the screws.
This power converter has a -20 / +60C operating temperature range and is UL 1310 Class 2 and CAN/CSA C22.2 No. 223-M91 rated. This unit has an 85% conversion efficiency and is suitable for use with moving LED signs and similar LED equipment.
Most Larson Electronics LEDLB, LEDP3W, LEDP10W, and LED10W series LED spotlights and floodlights are terminated with a Deutsch IPD / LADD DT04-2P connector. The mating connector plug is DT06-2S. Most LEDLB and LED10W series lights ship with mating connector as part of a harness or pigtail, depending on the model. Some larger LED lights like the LEDLB-160X2 or LEDLB-200X2 or multiple function LED lights (i.e. high/low beam, modulating, IR/Visible combos) will have different Deutsch connectors.
IL-LED-10W-M-1227 40° Flood Beam

Lamp Type:
Dimensions: 2 5/8 "W  2 5/8"-H  2 5/8"-Depth
Watts: 10
Voltage: 10-30 VDC
Line Out:
Line In Voltage:
Mounting:  Magnetic Base W/ 100lbs of Gripping Power
LED Life Expectancy: 25,000 hours
