Larson 400VA Remote Emergency Power Inverter - 90 Minute Emergency Run Time

Larson ElectronicsSKU: PL3-LEDEMG-400VA
filler

Price:
Sale price$11,299.99

Description

PuriLite suggests you place an order directly with us for large Larson orders due to the potential customization requirements. Please call us at 1-844-787-5483 to place your order. If you prefer to place your order online, a PuriLite agent will be in touch with you to discuss any custom options.
The LEDEMG-400VA from Larson Electronics is a 400V Emergency Lighting Inverter that works in conjunction with LED, fluorescent or incandescent lighting loads to create an emergency lighting system. The LEDEMG-400VA supports a maximum load of 400VA. This unit consists of a sealed lead calcium battery, charger and circuitry contained within a steel case. The LEDEMG-400VA provides power on the input side of connected fixtures including the ballast and can be used in both indoor and outdoor emergency lighting applications.
In the event of a normal power failure, the LEDEMG-400VA instantly begins to provide emergency power to connected fixtures for up to 90 minutes. During those 90 minutes, the unit will provide up to 91% of the lumen rating of the connected fixtures. Once normal power is restored, this emergency lighting inverter will begin to recharge. The battery capacity will be fully restored in 72 hours from the start of the recharge process.
Power:
The LEDEMG-400VA has an inpute voltage of 120V AC at 60HZ or 277V AC at 60Hz and an output voltage of 120V AC at 60Hz or 277V AC at 60Hz. The output frequency is synchronized to the connected utility within a +/- 2Hz range during emergencies. This remote emergency inverter has a <1 millisecond transfer time to inverter following a power failure.
Battery:
This unit features a maintenance-free sealed lead calcium battery. The 36V battery features automatic low-battery voltage disconnect and reverse polarity protection.
Installation:
The LEDEMG-400VA is a remote emergency lighting inverter and can be installed up to 1000 feet away from the fixture. It can be installed with both switched and unswitched fixtures.
Mounting:
The LEDEMG-400VA is designed to be surface mounted up to 1000 feet away from the emergency fixture.
Contact info@purilite.ca for more information about our custom options tailored to meet your specific industry needs.

Specifications
Type: Maintenance-free Sealed Lead Calcium
Battery Type: Maintenance-free Sealed Lead Calcium
Case Dimensions: 22" W x 8" D x 16" H
Weight: 132 lbs
Temperature Rating: 20°C to 30°C
Battery Voltage: 36V
Input Voltage: 120V AC 60Hz or 277V AC 60Hz
Output Voltage: 120V AC 60Hz or 277V AC 60Hz
Maximum Load Power: 400VA
Battery Recharge Time: 72 hours
Transfer Time: <1 ms
Output: Sine Wave
Case Material: Steel
Mounting: Surface Mount
Installation: Remote (Up To 1000` Away From Fixture)
Emergency Run Time: 90 minutes
Emergency Lumen Retention: 91%
Warranty: Yes- 3 Years*
