Ultraviolet LED Emitter - 330NM - (4) UV LEDs - NDT - 9-32V DC - Extreme Environment - IP68

Ultraviolet LED Emitter - 330NM - (4) UV LEDs - NDT - 9-32V DC - Extreme Environment - IP68

Sold by: LARSON ELECTRONICS

$5,900.00 CAD
$5,900.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications / Additional Information
LEDXHD-4E-UV-V1-330NM LED Light Bar Features
LEDs: (4) UV LED Emitters AlGaN Based
Dimensions: 4"-L  3"-H   3.56"-D IP68 Rated Waterproof to 3 meters
Weight: -
Voltage: 9-32V DC
UV Band: 330 nm (+/- 10 nm)
FWHM: 15nm
Intensity: <15 mW
Lighting Configuration: 35° Spot or 60° Flood
LED Chips: 36 Chip Dies
Current: 1.44A
Materials: Aluminum Housing, Polycarbonate
Lens Type: Flat Window or Hemispherical
Mounting: Stud Bracket
Wiring: Deutsch IPD/LADD DT04-2P connector
Color: Black
' Product Overview '
The Larson Electronics LEDXHD-4E-UV-V1-330NM is a powerful UV LED Light Bar for industrial work sites and NDT operations. Equipped with four UV LEDs, the low voltage emitter offers UV output with a wavelength measurement of 330 nm. The AIGaN-based unit is waterproof and protected by an aluminum housing and a polycarbonate lens. This waterproof UV LED lamp is offered in spot (35°) or flood (60°) beam configurations. The LEDXHD-4E-UV-V1-330NM produces UV light in the 330 nanometer spectrum with <15mW intensity. Four AlGaN-based UV LEDs are arranged in rows produce a 35-degree spot beam with limited spread and light spillage. We also offer optional floodlight versions with 60-degree optics to produce a wider beam spread and more light over a larger area nearer the fixture, making flood versions ideal for use as work and area lights. These UV LED light bars are IP68 rated and waterproof to 3 meters, sealed against intrusion by dust and dirt and very ruggedly constructed to withstand the most demanding environments, conditions and applications. The entire Larson Electronics LEDLB-E series are constructed of extruded aluminum and feature heavier housings, rubber isolated mounts and unbreakable polycarbonate lenses to provide increased durability against vibrations, impacts, waves, hard rains, sand and high winds.
Heat Management: Heat is the single largest factor in premature LED failure and color shifting. As a result, many manufacturers reduce the output of their LEDs to reduce the amount of heat produced. These LED light bars utilize an extruded aluminum housing that incorporates an advanced heat radiating fin design which dissipates heat efficiently to produce the maximum amount of power and longevity. The end result is more light and longer LED life with higher average lumen maintenance after 50,000 hours. Voltage Control: These units are able to monitor and adjust input current to maintain the correct LED voltage levels regardless of input levels across a specific range. These LEDLB series light bars can operate on current ranging from 9 to 32V DC without any modifications necessary as a result. This multi-voltage capability makes these units ideal for mobile and standalone applications such as those found on commercial boats, heavy equipment and vehicles where power systems don’t always operate with 12 volts and external generators, transformers or inverters are impractical.
35° Beam (Opt)
Durability: The LEDLB-E series of LED light bars from Larson Electronics offer IP68 rated construction that is designed to withstand extremes of environmental and operating conditions. The LED lights with the ‘E’ part number designation are designed for extreme durability and are larger and nearly twice as heavy as their standard counterparts. These units can withstand rapid temperature changes of -40 degrees Celsius to 85 degrees Celsius, are waterproof to three meters and resist ingress of dust, dirt and humidity. The housings are formed from thick extruded aluminum and the lenses are unbreakable polycarbonate. We recommend these LED lights for high stress - high vibratory conditions, high humidity climates, very cold areas and rough saltwater conditions. They are also well suited to environments where equipment is used in one temperature extreme and stored in another temperature extreme. Mounting: Larson Electronics LEDLB series light bars are equipped standard with aluminum mounting blocks which slide within the aluminum housing to allow users to adjust their positioning to match existing or user drilled mounting holes. Each aluminum mounting block has an integrated rubber bushing to absorb vibrations and shocks. To secure the lights in place users simply slide the mounting bolts through the aluminum mounting block and rubber isolator, through the mounting surface, then secure the bolt with a locking nut on the opposite side of the mounting surface. This mounting system enables mounting to flat or round surfaces and allows for minimal 7 degrees of flexibility of angle placement of the light. In this LED emitter light bar model, an additional mounting option is provided. The adjustable, shock insulated mounts are attached to a simple, inverted u-bracket type mount. The LED light bar can then be mounted via a single 3/8 bolt through the center of the bracket. We also offer a BC-2 bar clamp mounting system for even greater mounting versatility. Note: Most Larson Electronics LEDLB, LEDP3W, LEDP10W, and LED10W series LED spotlights and floodlights are terminated with a Deutsch IPD / LADD DT04-2P connector. The mating connector plug is DT06-2S. Most LEDLB and LED10W series lights ship with mating connector as part of a harness or pigtail, depending on the model. Some larger LED lights like the LEDLB-160X2 or LEDLB-200X2 or multiple function LED lights (i.e. high/low beam, modulating, IR/Visible combos) will have different Deutsch connectors. Applications: NDT, inspections, labs, outdoor locations, quality testing, industrial projects and more.
