Larson 300W Pneumatic Light Tower - (2) 150W LED Fixtures - 14'-36' Adjustable - 35,000 Total Lumens

Larson ElectronicsSKU: PL3-PLM-36-2XEPLC2.150RT-MOD1
filler

Price:
Sale price$39,532.00

Description

PuriLite suggests you place an order directly with us for large Larson orders due to the potential customization requirements. Please call us at 1(647) 254-9757 to place your order. If you prefer to place your order online, a PuriLite agent will be in touch with you to discuss any custom options.
The PLM-36-2XEPLC2.150RT-MOD1 from Larson Electronics is an Explosion Proof Pneumatic LED Flood Light Tower that provides operators with a powerful and energy efficient alternative to traditional hazardous location luminaries. LED technology and compact design makes this lamp an excellent replacement upgrade option for bulky and high maintenance cost older fixtures. The light boom can be extended to 36 feet for maximum area coverage and collapsed to 14 feet for more intense illumination. There is an additional light fixture mounted to the side of the mast located three feet above the ground.
Each Class I Division 2, Class II Division 1 & 2 explosion proof pneumatic LED flood light fixture on the PLM-36-2XEPLC2.150RT-MOD1 provides 17,500 lumens of high quality light while drawing only 150 watts. The copper free aluminum alloy body is powder coated for added durability and an attractive aesthetic appearance. Special heat dissipating design in conjunction with LED technology helps this fixture to achieve an excellent 60,000 hour rated lifespan with 80% lumen retention. Light weight and a low profile make this unit an attractive alternative to larger and heavier older fixtures and requires less hardware to install.
Each explosion proof LED light fixture features multiple LED drivers which helps to increase the operational life of the fixture. With traditional LED lights, in the event an LED array or driver fails, the entire fixture no longer illuminates. This new series of LED lamps contains twelve individual LED boards configured in a series of banks. Each bank contains two LED boards with an individual driver. In the event of a driver failure, only one bank of LEDs will be effected while the other banks will continue to operate. In the event that of an LED failure, the mating LED will continue to operate.
LED Benefits:
Unlike gas burning and arc type lamps that have glass bulbs, LEDs have no filaments or fragile housings to break during operation and/or transportation. Instead of heating a small filament or using a combination of gases to produce light, light emitting diodes (LEDs) use semi-conductive materials that illuminate when electric current is applied, providing instant illumination with no warm up or cool down time before re-striking. Because there is no warm up period, this light can be cycled on and off with no reduction in lamp life.
LED lights run at significantly cooler temperatures than traditional metal halide and high pressure sodium lights and contain no harmful gases, vapors, or mercury, making them both safer and more energy efficient. No extra energy is wasted in cooling enclosed work areas due to external heat emissions from bulb type lights, and the operator risks associated with traditional lighting methods, such as accidental burns and exposure to hazardous substances contained in the glass bulbs, are eliminated. In addition, LEDs are also safer for the environment as they are 100% recyclable, which eliminates the need for costly special disposal services required with traditional gas burning and arc type lamps.
This light tower is universal voltage capable and can be operated with 100-277 VAC, 50/60Hz. We also offer a low voltage version of this LED fixture that operates on AC/DC voltages from 11-25 Volts. This explosion proof LED light fixture is IP67 rated, dust-proof, and protected against high pressure jets and temporary submersion. The cast aluminum body and LED lamp give this light excellent durability and resistance to vibration and impacts. The housing is specially designed to dissipate heat which increases the efficiency and lifespan of the LEDs and electronics.
Each LED light on this pneumatic light tower produces 17,500 lumens of high-intensity LED light with a color temperature of 5600K and a color rendering index of 75 which produces colors and details much more accurately than high pressure sodium or mercury vapor luminaries. We also offer a 3000K warm white and 4500K natural white color temperature options (longer lead times may apply for non-standard temperatures).
Mounting:
The telescoping pneumatic light tower mast is designed to allow operators to quickly and safely deploy lighting and other electrical equipment in locations where this equipment must be elevated to heights up to 36 feet for effective application.
The tower is constructed of high strength, heat treated aluminum tubing for strength and durability. This tower is comprised of five sections, and includes a locking top mounting plate for easy removal of the light fixture. The mast is elevated using an air compressor (NOT included). An air release valve located at the base of this pneumatic mast allows operators to lower the tower. All wiring is internal, meaning no loose wiring when collapsed.
These light masts are typically mounted to trailers or other stable surfaces via a 12 inch square, ½ inch thick mounting base-plate which has been drilled to accept four mounting bolts (3/4 inch). This light tower weighs 320 lbs, and can easily support and lift 150+ lbs fixtures. When fully extended, this light tower can withstand winds up to 70 mph without guys. The entire tower assembly is shipped via common freight carrier and when shipped measures approximately 12 feet long, 4 feet wide, 3 feet tall and weighs 350 lbs. Larson Electronics can custom tailor these units to the customer’s requirements with longer sections and larger mounting plates.
Contact info@purilite.ca for more information about our custom options tailored to meet your specific industry needs.

Specifications
Listing:
Lamp Type:
Dimensions: 14"H x 16"W 5"D
Weight: Light Head: 32 lb; Total Weight w/ Tower: 384 lb 320 lb (Tower Only) 414 lb
Voltage: 100-277 Volts AC, 50/60Hz or 11-25 Volts AC/DC
Total Watts: 150 W
Total Lumens: 17,500
Luminous Efficiency: 166.67 Lm/W
Lamp Life: 60,000+ Hours
Color Temp: 5600K, 4500K, or 3000K
Color Rendering Index: >75 CRI
Beam Angle: 60° or 125°
Lighting Configuration: Flood Pattern
Power Efficiency: >95%
Power Factor: 0.992
Amperage: 1.25 A @ 120 V, 0.63 A @ 240 V, 0.54 A @ 277 V
Maximum Inrush Current: 1.65 A @ 120 V
Ambient Operating Temp Range: -50°C to +65°C
Operating Temp Rating: T5
Housing Material: Copper Free Cast Aluminum
Lens Material: Hardened Borosilicate Glass
Gasket Material: Silicone
Mounting: Pneumatic Tower - Surface Mount
Wiring: 10` 16/3 SOOW w/ Flying Leads
Wiring Hub: 3/4" NPT
LED Driver Specs
Input Voltage: 100-277 Volts AC
Input Current: 1.8 A Max
Output Voltage: 54 V Max
Output Current: 2.1 A
Tower Specs
Length: 14` to 36`
Weight: Light Head: 32 lb; Total Weight w/ Tower: 384 lb 320 lb (Tower Only) 414 lb
Capacity: 150 lb
Materials: Heat Treated 6063B/T5 Aluminum
Mounting: Pneumatic Tower - Surface Mount
Shipping: Standard Freight
Shipping Weight: 414 lb
