15HP Variable Frequency Device - 208-240V AC 3PH Input/Output - 61 Amps - NEMA 12

LARSON ELECTRONICSSKU: PL3-VFD-208.240-3P-61A
filler

Price:
Sale price$11,262.00

Description

Specifications / Additional Information
VFD-208.240-3P-61A Variable Frequency Device Features/Ratings
Unit Type: Variable Frequency Device NEMA 12
Dimensions: 22" x 7.6" x 9.3" IP54
Weight: 40 lbs Fan Cooled
Input/Output Voltage: 208-240V AC 3PH
Output Current: 61 Amps
Operating Frequency: 0 to 320 Hz
HP: 15
Digital Inputs: 6 Inputs (NPN)
Digital Outputs: 1 Output (NPN), 2 Outputs (Relay)
Analog Input/Output: 1 Input (0 - 10V DC/0 - 20 mA), 1 Output (0 - 20 mA)
Operating Temp: 15°C to +50°C
Materials: -
Mounting: Surface
Color: Gray
' Product Overview '
Made in the USA The Larson Electronics VFD-208.240-3P-61A Variable Frequency Drive is suitable for improving AC motor performance in industrial operations. This fan-cooled unit features three-phase 208-240V AC input/output voltage compatability. The NEMA 12-rated device supports six digital inputs, three digital outputs and a total of four operating modes (Open Loop Vector Control, Speed Control, Torque Control - Constant and Torque Control - Variable. The VFD-208.240-3P-61A offers accurate AC motor control in industrial facilities. This unit is compatible with three-phase 208-240V AC input/output voltage. Designed for steady speed error, fast torque rise and protection from resonance vibrations, the device provides an output current of 61 amps and an operating frequency range of 0 to 320 Hz. This 15-horsepower unit comes with a total of six digital inputs (NPN) and three digital outputs (NPN and Relay). The VFD-208.240-3P-61A is designed for indoor applications and operating temperatures ranging between 15°C to +50°C. Operators may mount the variable frequency drive on compatible surfaces. This device measures 22" x 7.6" x 9.3" and weighs 40 lbs. Applications: Speed control of AC motors, industrial machines, large compressors, energy savings and more.
