100A Military Plug - 120/208V AC - Male, (8) Positions - Protective Cap
100A Military Plug - 120/208V AC - Male, (8) Positions - Protective Cap
| XLE-MS90556C44412P Military Male Plug | Ratings |
| Unit Type: Military Male Plug | MIL-DTL-22992, Class L |
| Dimensions: 10.172" x 3.531" | Environment Resistant |
| Weight: - |  |
| Voltage Rating: 120/208V AC |  |
| Amps Rating: 100A |  |
| Gender: Male |  |
| Positions: 8 |  |
| Shell Size - Insert: 44-12 |  |
| Orientation: 4 |  |
| Mating Receptacle/Connector: XLE-MS90555C44412S |  |
| Fastening Type: Threaded |  |
| Features/Protection: Backshell, Coupling Nut, Protective Cap |  |
| Shell, Backshell, Plating Material: Aluminum |  |
| Contact Material: Copper Alloy | |
| Contact Finish - Mating: Gold | |
| Contact Finish Thickness - Mating: 50.0µin | |
| Mount: Free Hanging (In-Line) | |
| Termination: Crimp | |
| Cable Range: 1.391" - 1.516" |
| The Larson Electronics XLE-MS90556C44412P Military Male Plug allows operators to make secure connections to power sources in rugged environments. This 100-amp unit is compatible with 120/208V AC. Equipped with a protective cap, there are eight positions on the plug. The XLE-MS90556C44412P is a heavy-duty power plug for military applications. This Class L male plug is rated at 100 amps and 120/208V AC. Featuring a shell insert size of 44-12, the unit features a backshell, coupling nut and a protective cap. The shell, backshell and plating is constructed aluminum, while the contacts are copper alloy. This environment resistant plug accepts a cable range of 1.391" - 1.516". The plug mates with the Larson Electronics XLE-MS90555C44412S female connector. Applications: Electrical connections, power distribution, connection to power sources and more. |
|  |
