Super Micro Supermicro SC813MT-410C Chassis - Rack-mountable - Black

Super MicroSKU: PL5-CSE-813MT-410CB-84774Z-EN
filler

Price:
Sale price$479.99

Description

Supermicro SC813MT-410C Chassis - Rack-mountable - Black

The SC813M 1U Chassis is a density-optimized mid-level server chassis, ideal for storage and datacenters. With a depth of only 19.85", it's compact design houses ATX motherboards of up to 12" x 10" and supports one Full-height, Half-length PCI addon card.

Number of Total Expansion Slots 1
Number of External 5.25" Bays 1
Number of Total Expansion Bays 5
Front USB Yes
Total Number of USB Ports 2
Additional Information
    • 1U chassis support for max. motherboard size - 12" x 10" ATX
    • 1 x Full-height, half-length PCI expansion slot (with Riser Card)

    Front Panel:

    • Buttons:
    • Power On/Off
    • System Reset
    • LEDs:
    • Power
    • Hard drive activity
    • 2 x Network activity
    • System Overheat

    Power Supply:

    • 410W DC power supply (24-pin)
    • Nominal Voltage = -48V
    • DC Output: 5V + 3.3V, 160W
    • 5V, 35.0 Amp
    • 5V standby, 3.0 Amp
    • 12V, 32.0 Amp
    • -12V, 0.5 Amp
    • 3.3V, 20.0 Amp
Package Contents
  • 1 x SC813MT-410C Chassis
  • 1 x 410W SP410-1D DC 1U Power Supply
  • 4 x 1U, 4cm Sanyo 12,500 RPM High-Performance Fan
  • 1 x 1U Slide Rails
  • 4 x SCA Hard Drive Carriers
  • 1 x 4 x 1" SATA Backplane
  • 1 x Floppy Disk Drive Round Cable
  • 1 x Front Panel Ribbon Cable (BOM)
  • 1 x SATA (18") Activity LED Cable
  • 4 x SATA (13.8") Cable
  • 1 x 16-pin Front Panel Split Cable
  • 1 x Front USB and COM Port Tray
Product Type Server Case
Manufacturer Part Number CSE-813MT-410CB
Manufacturer Website Address http://www.supermicro.com
Manufacturer Supermicro Computer, Inc
Product Model SC813MT-410C
Product Name SC813MT-410C Chassis
Brand Name Supermicro
Number of Power Supplies Installed 1
Power Supply Wattage 410 W
Motherboard Supported ATX
Number of Fans Installed 4
Weight (Approximate) 14.06 kg
Color Black
Form Factor Rack-mountable
Height 1.70" (43.18 mm)
Width 17.20" (436.88 mm)
Depth 19.80" (502.92 mm)
Compatible Rack Unit 1U
