Super Micro Supermicro X11SAT Workstation Motherboard - Intel Chipset - Socket H4 LGA-1151 - ATX - 64 GB DDR4 SDRAM Maximum RAM - DIMM, UDIMM - 4 x Memory Slots - Gigabit Ethernet - HDMI - DisplayPort - 6 x SATA Interfaces

Save 21%
Super MicroSKU: PL5-MBD-X11SAT-O-83491Z-EN
filler

Price:
Sale price$443.99 Regular price$561.11
 More payment options

Description

Supermicro X11SAT Workstation Motherboard - Intel Chipset - Socket H4 LGA-1151 - ATX - 64 GB DDR4 SDRAM Maximum RAM - DIMM, UDIMM - 4 x Memory Slots - Gigabit Ethernet - HDMI - DisplayPort - 6 x SATA Interfaces

Xeon® E3-1200 v5 Family Boards / Socket H4 (LGA 1151)

Supermicro's single processor Socket H4 designs feature the Intel® C236 chipset which support the Intel® Xeon E3-1200 v5 processor family and Intel® 6th Gen Core i7/i5/i3 processor family. With outstanding features that include up to 64GB of fast DDR4 DRAM in 4 DIMMS, onboard IPMI or vPro, USB 3.0/USB 3.1, PCI-E 3.0 M.2 and SATA 3.0 (6Gbps) HDD. With support for next generation graphics controller, 4K HD graphics resolution and 3 displays with HDMI, DP, and DVI ports. Designed with performance, reliability, manageability and long life in mind, Supermicro's single processor motherboards are the perfect solution for a variety of server, workstation and embedded applications.
Compatibility
    Supermicro Chassis:

    Mid/Mini Tower Chassis:
    • SC732D4-903B
    • SC732D4-865B

    4U / Tower Chassis:
    • SC743TQ-1200B-SQ
Gigabit Ethernet Yes
Form Factor ATX
Width 12" (304.80 mm)
Depth 9.60" (243.84 mm)
Graphics Controller Manufacturer ASPEED
Graphics Controller Model AST2400
Onboard Video On-board Video Chipset
Number of PCI Express x1 Slots 1
Number of Total Expansion Slots 5
Number of PCI Express x16 Slots 3
Total Number of PCI Express Slots 4
Number of SATA Interfaces 6
Total Number of Onboard USB Ports 8
Number of Onboard USB 3.0 Ports 4
Number of M.2 Interfaces 1
RAID Levels 5
10
1
0
Controller Type Serial ATA/600
RAID Supported Yes
HDMI Yes
DVI Yes
DisplayPort Yes
Total Number of USB Ports 5
Number of USB 3.0 Ports 2
Number of USB 3.1 Ports 1
Processor Supported Core i7
Core i3
Core i5
Xeon
Total Processor Supported 1
Processor Socket Socket H4 LGA-1151
Chipset Manufacturer Intel
Product Type Workstation Motherboard
Manufacturer Part Number MBD-X11SAT-O
Manufacturer Website Address http://www.supermicro.com
Manufacturer Supermicro Computer, Inc
Product Model X11SAT
Product Name X11SAT Workstation Motherboard
Package Type Retail
Brand Name Supermicro
Maximum Memory Supported 64 GB
Memory Technology DDR4 SDRAM
Number of Memory Slots 4
Memory Form Factor DIMM
UDIMM
Memory Speed Supported 2133 MHz
1866 MHz
1600 MHz
