Super Micro Supermicro X8DT3-LN4F Server Motherboard - Intel Chipset - Socket B LGA-1366 - Extended ATX - 96 GB DDR3 SDRAM Maximum RAM - DDR3-1333/PC3-10600, DDR3-1066/PC3-8500, DDR3-800/PC3-6400 - 12 x Memory Slots - Gigabit Ethernet - 6 x SATA Interfac

Super MicroSKU: PL5-MBD-X8DT3-LN4F-O-83436Z-EN
filler

Price:
Sale price$712.99

Description

Supermicro X8DT3-LN4F Server Motherboard - Intel Chipset - Socket B LGA-1366 - Extended ATX - 96 GB DDR3 SDRAM Maximum RAM - DDR3-1333/PC3-10600, DDR3-1066/PC3-8500, DDR3-800/PC3-6400 - 12 x Memory Slots - Gigabit Ethernet - 6 x SATA Interfaces

This X8DT3-LN4F Server Board is designed with the utmost attention to detail to provide the highest standards in quality and performance. X8DT3-LN4F supports the Intel 5500 Series Processor platform, the first dual-processing platform that supports the Intel Quick Path Interconnect (QPI) Technology, providing the next generation point-to-point system interface to replace the current Front Side Bus.

Gigabit Ethernet Yes
Form Factor Extended ATX
Width 12" (304.80 mm)
Depth 13" (330.20 mm)
Graphics Controller Manufacturer Matrox
Graphics Controller Model G200eW
Onboard Video On-board Video Chipset
Additional Information

    System BIOS:

    • 32Mb SPI Flash EEPROM with AMI BIOS
    • Plug and Play (PnP)
    • PCI 2.2
    • ACPI up to 3.0
    • USB Keyboard Support
Package Contents
  • X8DT3-LN4F Server Board
  • 4 x 57.5cm SATA Flat S-S PBF
  • 1 x USB Cable
  • 2 x 50cm IPASS To 4 SATA,PB Free
  • 1 x 9-Pin Serial Port DTK Cable, LF
  • 1 x ATX Floppy Cable
  • 1 x Driver CD
  • 1 x I/O Shield
  • 1 x User Manual
Environmentally Friendly Yes
Environmental Certification RoHS
Number of SATA Interfaces 6
Number of SAS Interfaces 8
Total Number of Onboard USB Ports 4
Onboard LEDs Header Yes
Number of PCI Slots 2
Number of Total Expansion Slots 7
Number of PCI Express x4 Slots 1
Number of PCI Express x8 Slots 3
Total Number of PCI Express Slots 4
VGA Yes
Network (RJ-45) Yes
Serial Port Yes
Total Number of USB Ports 4
Number of USB 2.0 Ports 4
PS/2 Port Yes
Number of PS/2 Ports 2
Product Type Server Motherboard
Manufacturer Part Number MBD-X8DT3-LN4F-O
Manufacturer Website Address http://www.supermicro.com
Manufacturer Supermicro Computer, Inc
Product Model X8DT3-LN4F
Product Name X8DT3-LN4F Server Motherboard
Package Type Retail
Brand Name Supermicro
RAID Levels 1
1+0
5
0
Controller Type Serial Attached SCSI (SAS)
Serial ATA/300
Floppy Controller
RAID Supported Yes
Processor Supported Xeon Quad-core
Xeon Dual-Core
Total Processor Supported 2
Processor Socket Socket B LGA-1366
Processor Technology Enhanced SpeedStep Technology
64-bit Processing Yes
Chipset Manufacturer Intel
QuickPath Interconnect 6.40 GT/s
Maximum Memory Supported 96 GB
Memory Technology DDR3 SDRAM
Memory Standard DDR3-1333/PC3-10600
DDR3-1066/PC3-8500
DDR3-800/PC3-6400
Number of Memory Slots 12
Memory Speed Supported 1066 MHz
800 MHz
1333 MHz
