Super Micro Supermicro X8DTH-iF Server Motherboard - Intel Chipset - Socket B LGA-1366 - Extended ATX - 96 GB DDR3 SDRAM Maximum RAM - DDR3-1333/PC3-10600, DDR3-1066/PC3-8500, DDR3-800/PC3-6400 - 12 x Memory Slots - Gigabit Ethernet - 6 x SATA Interfaces

Super MicroSKU: PL5-MBD-X8DTH-IF-O-83428Z-EN
filler

Price:
Sale price$681.99

Description

Supermicro X8DTH-iF Server Motherboard - Intel Chipset - Socket B LGA-1366 - Extended ATX - 96 GB DDR3 SDRAM Maximum RAM - DDR3-1333/PC3-10600, DDR3-1066/PC3-8500, DDR3-800/PC3-6400 - 12 x Memory Slots - Gigabit Ethernet - 6 x SATA Interfaces

This X8DTH-iF Server Board is designed with the utmost attention to detail to provide the highest standards in quality and performance. X8DTH-iF supports the Intel 5500 Series Processor, the first dual-processor platform that supports the Intel QuickPath Interconnect (QPI) Technology, providing the next generation point-to-point system interface to replace the current Front Side Bus.

Gigabit Ethernet Yes
Number of Total Expansion Slots 8
Number of PCI Express x8 Slots 7
Total Number of PCI Express Slots 7
Number of SATA Interfaces 6
Total Number of Onboard USB Ports 4
Onboard LEDs Header Yes
Form Factor Extended ATX
Width 12" (304.80 mm)
Depth 13" (330.20 mm)
Graphics Controller Manufacturer Matrox
Graphics Controller Model G200eW
Onboard Video On-board Video Chipset
Additional Information

    System BIOS:

    • 32Mb SPI Flash EEPROM with AMI BIOS
    • Plug and Play (PnP)
    • PCI 2.2
    • ACPI up to 3.0
    • USB Keyboard Support
Package Contents
  • X8DTH-iF Server Board
  • 1 x ATX Floppy Cable
  • 1 x ATA 66/100 IDE LP Cable
  • 6 x 2ft. Amphenol, SATA Cable
  • 1 x I/O Shield
  • 1 x CPU Retention Module
Environmentally Friendly Yes
Environmental Certification RoHS
RAID Levels 0
1
1+0
5
Controller Type Serial ATA/300
RAID Supported Yes
VGA Yes
Network (RJ-45) Yes
Serial Port Yes
Total Number of USB Ports 4
Number of USB 2.0 Ports 4
PS/2 Port Yes
Number of PS/2 Ports 2
Product Type Server Motherboard
Manufacturer Part Number MBD-X8DTH-IF-O
Manufacturer Website Address http://www.supermicro.com
Manufacturer Supermicro Computer, Inc
Product Model X8DTH-iF
Product Name X8DTH-iF Server Motherboard
Package Type Retail
Brand Name Supermicro
Processor Supported Xeon Dual-Core
Xeon Quad-core
Total Processor Supported 2
Processor Socket Socket B LGA-1366
Processor Technology Enhanced SpeedStep Technology
64-bit Processing Yes
Chipset Manufacturer Intel
QuickPath Interconnect 6.40 GT/s
Maximum Memory Supported 96 GB
Memory Technology DDR3 SDRAM
Memory Standard DDR3-1066/PC3-8500
DDR3-1333/PC3-10600
DDR3-800/PC3-6400
Number of Memory Slots 12
Memory Speed Supported 1333 MHz
800 MHz
1066 MHz
