Super Micro Supermicro X9DRH-7F Server Motherboard - Intel Chipset - Socket R LGA-2011 - Extended ATX - 512 GB DDR3 SDRAM Maximum RAM - DDR3-1600/PC3-12800, DDR3-1333/PC3-10600, DDR3-1066/PC3-8500, DDR3-800/PC3-6400 - 16 x Memory Slots - Gigabit Ethernet

Super MicroSKU: PL5-MBD-X9DRH-7F-O-83368Z-EN
filler

Price:
Sale price$898.99

Description

Supermicro X9DRH-7F Server Motherboard - Intel Chipset - Socket R LGA-2011 - Extended ATX - 512 GB DDR3 SDRAM Maximum RAM - DDR3-1600/PC3-12800, DDR3-1333/PC3-10600, DDR3-1066/PC3-8500, DDR3-800/PC3-6400 - 16 x Memory Slots - Gigabit Ethernet - 10 x SATA Interfaces

Major Benefits from Supermicro's in-house Design Superiority

Supermicro motherboard advantages:

  • Technologically-advanced Motherboard Designs Since 1993
  • Consistent highest-quality Design, Components, and Production Expertise
  • Extensive Range of x86 Serverboards Available
  • Competitive Price/Performance
  • High Performance Boards Supporting the Latest CPU, memory, and add-on Hardware
  • Standard Form Factors offer Feature - rich Support and application optimization

These competitive advantages help Supermicro maintain its design leadership in providing state-of-the-art motherboards for a wide range of applications. Always a step ahead of the competition, Supermicro is consistently first-to-market in delivering high-performance technology support. Offering the most extensive serverboard selection in the industry at competitive prices, Supermicro boards are quality-built to maximize customer satisfaction.

Gigabit Ethernet Yes
Power Supply Supported EPS12V
Limited Warranty 3 Year
Certifications & Standards
    • ACPI 2.0
    • ACPI
    • APM 1.2
Environmentally Friendly Yes
Environmental Certification RoHS-6
Form Factor Extended ATX
Height 13" (330.20 mm)
Width 12" (304.80 mm)
Graphics Controller Manufacturer Matrox
Graphics Controller Model G200
Onboard Video On-board Video Chipset
Number of Total Expansion Slots 7
Number of PCI Express x8 Slots 2
Number of PCI Express x16 Slots 5
PCI Express Standard PCI Express 3.0
Total Number of PCI Express Slots 7
Number of SATA Interfaces 10
Number of SAS Interfaces 8
Total Number of Onboard USB Ports 3
Number of Onboard USB 2.0 Ports 3
Onboard LEDs Header Yes
Onboard Serial Header Yes
Maximum Memory Supported 512 GB
Memory Technology DDR3 SDRAM
Memory Standard DDR3-1333/PC3-10600
DDR3-800/PC3-6400
DDR3-1600/PC3-12800
DDR3-1066/PC3-8500
Number of Memory Slots 16
Memory Form Factor UDIMM
RDIMM
Memory Speed Supported 800 MHz
1600 MHz
1333 MHz
1066 MHz
Processor Supported Xeon
Total Processor Supported 2
Processor Socket Socket R LGA-2011
64-bit Processing Yes
Chipset Manufacturer Intel
QuickPath Interconnect 8 GT/s
Product Type Server Motherboard
Manufacturer Part Number MBD-X9DRH-7F-O
Manufacturer Website Address http://www.supermicro.com
Manufacturer Supermicro Computer, Inc
Product Model X9DRH-7F
Product Name X9DRH-7F Server Motherboard
Package Type Retail
Brand Name Supermicro
VGA Yes
Number of Network (RJ-45) Ports 3
Network (RJ-45) Yes
Audio Line In No
Audio Line Out No
Serial Port Yes
Microphone Port No
Total Number of USB Ports 4
Number of USB 2.0 Ports 4
RAID Levels 50
60
5
1+0
1
0
6
Controller Type Serial ATA/300
6Gb/s SAS
Serial ATA/600
RAID Supported Yes
