Super Micro Supermicro X9DRH-iTF Server Motherboard - Intel Chipset - Socket R LGA-2011 - Extended ATX - 512 GB DDR3 SDRAM Maximum RAM - DDR3-1600/PC3-12800, DDR3-1333/PC3-10600, DDR3-1066/PC3-8500, DDR3-800/PC3-6400 - DIMM, RDIMM, UDIMM, LRDIMM - 16 x M

Super MicroSKU: PL5-MBD-X9DRH-ITF-O-83369Z-EN
filler

Price:
Sale price$816.99

Description

Supermicro X9DRH-iTF Server Motherboard - Intel Chipset - Socket R LGA-2011 - Extended ATX - 512 GB DDR3 SDRAM Maximum RAM - DDR3-1600/PC3-12800, DDR3-1333/PC3-10600, DDR3-1066/PC3-8500, DDR3-800/PC3-6400 - DIMM, RDIMM, UDIMM, LRDIMM - 16 x Memory Slots - Gigabit Ethernet - 10 x SATA Interfaces

Major Benefits from Supermicro's in-house Design Superiority

Supermicro motherboard advantages:

  • Technologically-advanced Motherboard Designs Since 1993
  • Consistent highest-quality Design, Components, and Production Expertise
  • Extensive Range of x86 Serverboards Available
  • Competitive Price/Performance
  • High Performance Boards Supporting the Latest CPU, memory, and add-on Hardware
  • Standard Form Factors offer Feature - rich Support and application optimization

These competitive advantages help Supermicro maintain its design leadership in providing state-of-the-art motherboards for a wide range of applications. Always a step ahead of the competition, Supermicro is consistently first-to-market in delivering high-performance technology support. Offering the most extensive serverboard selection in the industry at competitive prices, Supermicro boards are quality-built to maximize customer satisfaction.

Gigabit Ethernet Yes
Power Supply Supported EPS12V
Limited Warranty 3 Year
Form Factor Extended ATX
Width 13" (330.20 mm)
Depth 12" (304.80 mm)
Graphics Controller Manufacturer Matrox
Graphics Controller Model G200eW
Onboard Video On-board Video Chipset
Package Contents
  • X9DRH-iTF Server Motherboard
  • 6 x I/O Cables
Certifications & Standards
    • FCC
    • CE
Environmentally Friendly Yes
Environmental Certification RoHS-6
Number of Total Expansion Slots 7
Number of PCI Express x8 Slots 6
Number of PCI Express x16 Slots 1
PCI Express Standard PCI Express 3.0
Total Number of PCI Express Slots 7
Number of SATA Interfaces 10
Total Number of Onboard USB Ports 3
Number of Onboard USB 2.0 Ports 3
Onboard LEDs Header Yes
Onboard Serial Header Yes
Maximum Memory Supported 512 GB
Memory Technology DDR3 SDRAM
Memory Standard DDR3-1333/PC3-10600
DDR3-1600/PC3-12800
DDR3-1066/PC3-8500
DDR3-800/PC3-6400
Number of Memory Slots 16
Memory Form Factor LRDIMM
UDIMM
RDIMM
DIMM
Memory Speed Supported 1600 MHz
1333 MHz
1066 MHz
800 MHz
RAID Levels 1+0
5
1
0
Controller Type Serial ATA/600
Serial ATA/300
RAID Supported Yes
Processor Supported Xeon
Total Processor Supported 2
Processor Socket Socket R LGA-2011
Processor Technology Virtualization Technology
64-bit Processing Yes
Chipset Manufacturer Intel
QuickPath Interconnect 8 GT/s
Product Type Server Motherboard
Manufacturer Part Number MBD-X9DRH-ITF-O
Manufacturer Website Address http://www.supermicro.com
Packaged Quantity 1
Manufacturer Supermicro Computer, Inc
Product Model X9DRH-iTF
Product Name X9DRH-iTF Server Motherboard
Package Type Retail
Brand Name Supermicro
VGA Yes
Number of Network (RJ-45) Ports 3
Network (RJ-45) Yes
Audio Line In No
Audio Line Out No
Serial Port Yes
Microphone Port No
Total Number of USB Ports 4
Number of USB 2.0 Ports 4
