Super Micro Supermicro X9DRL-7F Server Motherboard - Intel Chipset - Socket R LGA-2011 - ATX - 512 GB DDR3 SDRAM Maximum RAM - 8 x Memory Slots - Gigabit Ethernet - 6 x SATA Interfaces

Super Micro Supermicro X9DRL-7F Server Motherboard - Intel Chipset - Socket R LGA-2011 - ATX - 512 GB DDR3 SDRAM Maximum RAM - 8 x Memory Slots - Gigabit Ethernet - 6 x SATA Interfaces

Regular price $688.99 CAD
Regular price $872.80 CAD Sale price $688.99 CAD
Sale Sold out
Shipping calculated at checkout.

Supermicro X9DRL-7F Server Motherboard - Intel Chipset - Socket R LGA-2011 - ATX - 512 GB DDR3 SDRAM Maximum RAM - 8 x Memory Slots - Gigabit Ethernet - 6 x SATA Interfaces

Xeon® E5 Family BOARDS / Socket R (LGA 2011)

Supermicro's New Generation X9 Serverboards offer the highest levels of performance, efficiency and scalability in the industry. The Supermicro X9 Serverboards are available in a variety of architectures including Twin and new Fat Twin, GPU Supercomputer, Data Center Optimized, SuperServer® Advantage, I/O Optimized, SuperWorkstation, and SuperStorage Solutions. These Serverboards offers numerous advantages including up to 1.5TB DDR3 (up to 1866MHz) memory in 24 DIMM slots, SATA 3.0 and SAS 3.0 (12Gbps) HDD support, ConnectX FDR/QDR InfiniBand ports, dual 10 Gigabit Ethernet, Quad Ethernet LAN, PCI-E 3.0 technology, LSI® 2308 controller with software RAID and LSI® 2208 controller with hardware RAID, IPMI 2.0, and Intel® Xeon® processor E5-2600 or E5-2600 v2 family for highest performance. With this New Generation X9 Serverboard Platform Supermicro offers the most extensive selection of solutions for Data Center, Enterprise IT, Cloud Computing, Graphics, Technical Computing, and HPC environments.
Gigabit Ethernet Yes
Form Factor ATX
Width 12" (304.80 mm)
Depth 10" (254 mm)
Graphics Controller Manufacturer Matrox
Graphics Controller Model G200eW
Onboard Video On-board Video Chipset
Package Contents
  • X9 Series X9DRL-7F Server Motherboard
  • 8 x SATA CABLE 61CM FLAT S-S PBF
  • 1 x STD I/O Shield For X9 socket R Server MB With Gasket
Compatibility
    1U Chassis:
    • CSE-813MFTQ-441CB
    • CSE-813MFTQ-R400CB
    2U Chassis:
    • CSE-826TQ-653B
    3U Chassis:
    • CSE-833T-653B
    Mid-Tower:
    • CSE-732i-500B
    Tower / 4U Rackmount:
    • CSE-842TQ-665B
    • CSE-842TQ-865B
Certifications & Standards
    • ACPI 4.0
Environmentally Friendly Yes
Environmental Certification RoHS-6
Number of PCI Express x1 Slots 1
Number of Total Expansion Slots 4
Number of PCI Express x8 Slots 3
PCI Express Standard PCI Express 2.0
PCI Express 3.0
Total Number of PCI Express Slots 4
Maximum Memory Supported 512 GB
Memory Technology DDR3 SDRAM
Memory Standard DDR3-1800/PC3-14400
DDR3-1066/PC3-8500
DDR3-1600/PC3-12800
DDR3-800/PC3-6400
DDR3-1333/PC3-10600
Number of Memory Slots 8
Memory Form Factor RDIMM
LRDIMM
DIMM
UDIMM
Memory Speed Supported 1600 MHz
1800 MHz
1333 MHz
800 MHz
1066 MHz
VGA Yes
Number of Network (RJ-45) Ports 3
Network (RJ-45) Yes
Serial Port Yes
Total Number of USB Ports 4
Number of USB 2.0 Ports 4
Number of SATA Interfaces 6
Number of SAS Interfaces 8
Total Number of Onboard USB Ports 3
Number of Onboard USB 2.0 Ports 3
Onboard LEDs Header Yes
Onboard Serial Header Yes
Processor Supported Xeon
Total Processor Supported 2
Processor Socket Socket R LGA-2011
64-bit Processing Yes
Chipset Manufacturer Intel
QuickPath Interconnect 8 GT/s
RAID Levels 1
0
5
1+0
Controller Type Serial ATA/600
6Gb/s SAS
Serial ATA/300
RAID Supported Yes
Product Type Server Motherboard
Manufacturer Part Number MBD-X9DRL-7F-O
Manufacturer Website Address http://www.supermicro.com
Manufacturer Supermicro Computer, Inc
Product Model X9DRL-7F
Product Name X9 Series X9DRL-7F Server Motherboard
Package Type Retail
Product Series X9
Brand Name Supermicro
