Tripp Lite SmartPro SMART1524ET 1500VA Rack-mountable UPS - 3U Rack-mountable - AVR - 120 V AC Input - 120 V AC Output

Save 25%
Tripp LiteSKU: PL5-SMART1524ET-464A1H-0037332241214-EN
filler

Price:
Sale price$3,050.99 Regular price$4,044.51

Description

Tripp Lite SmartPro SMART1524ET 1500VA Rack-mountable UPS - 3U Rack-mountable - AVR - 120 V AC Input - 120 V AC Output

1.5kVA/1.2kW/120V Battery Backup for Applications in Low- and High-Temperature Extremes

This SmartPro® line-interactive SMART1524ET UPS system with hardwire AC input/output offers a wide operating temperature range and provides constant and reliable backup power to critical equipment in harsh environments, including outdoor and industrial equipment. It prevents surges, spikes, overvoltage, undervoltage and blackouts from damaging equipment, destroying data and contributing to costly downtime.

Ideal for Running Networking, Security or Traffic Equipment in -40°C to 80°C Temperatures

The SMART1524ET is ideal protection for a wide variety of industry-specific IT, communications, edge computing, security, surveillance, traffic signage and traffic camera equipment in remote locations where temperatures are typically within -40°C and 55°C (for max output), -40°C and 75°C (for up to 1200W output) or -40°C and 80°C (for up to 1000W output). Internal circuitry is covered with a conformal coating that protects against extreme temperatures. Applications range from oil fields, offshore oil rigs and other industrial locations to remote security and military applications to traffic-related setups involving signals and cameras.

Reliable, Expandable Battery Backup Keeps You Operational Through Power Outages

Backup support allows you to safely maintain the operation of critical traffic/industrial equipment and other applications requiring reliable extended UPS runtime in demanding environments. A battery connector kit with wireable contact pins lets you connect your own 24V battery banks up to 200Ah (batteries and cables not included). A temperature sensor monitors the battery terminals and customizes charging to optimum levels to extend the lifespan of the connected batteries.

Optional WEBCARDLXMINI Network Interface Offers 24/7 Remote Access for Monitoring and Control

The Java-free HTML5-based WEBCARDLXMINI (sold separately) enables full remote access for site power and UPS status monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Automated alerts help prevent accidental overloads, power loss and downtime. WEBCARDLXMINI allows you to use the Auto Probe feature, which can prevent costly service calls by automatically rebooting non-responsive network devices. Note: WEBCARDLXMINI has a temperature range of 0°C to 70°C, as measured inside the UPS housing.

Built-in Input/Output Dry Contacts and 24V DC Temperature-Controlled Fan Power Outlet

Six sets of output dry contacts support Normally Open (NO) or Normally Closed (NC) signaling of user-configurable UPS conditions, such as On Battery, Low Battery or UPS Fault to other integrated devices. One set of input dry contacts supports the connection of one user-supplied contact-closure sensor for remote notification via WEBCARDLXMINI and local notification via front-panel LCD. A temperature-controlled 24V DC output power jack supports optional user-supplied fan installation to control over-temperature conditions in equipment enclosures.

Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions

AVR protects your equipment from incremental hardware damage, data loss and performance problems caused by brownouts and overvoltages. The SMART1524ET can correct brownouts as low as 88V and overvoltages as high as 152V with user-configurable buck-and-boost settings, all while keeping the battery fully charged and ready to take over in case of power failure.

Features
  • Recommended for remote locations where temperatures range within -40°C and 80°C
  • Protects equipment against blackouts, brownouts, overvoltages, surges and line noise
  • Keeps power running during prolonged outages to allow time for safe system shutdown
  • Maintains continuous 120V nominal output during brownouts and overvoltages
  • Optional WEBCARDLXMINI network interface supports Auto Probe feature
  • 2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty.
  • $250,000 Ultimate Lifetime Insurance
DC System Voltage 24 V DC
Status Indicators

    Four Line Text-Based Front Panel LCD:

    • Provides Full Access To UPS Status
    • Alarms
    • Faults
    • Events
    • Settings and Control Options

    LED Indicators:

    • Set Of 3 Front Panel LEDs Report AC Output Status (Green)
    • Alarm Condition (Yellow)
    • Fault Condition (Red)
Limited Warranty 3 Year
Serial Port Yes
USB (HID Compliant) Port Yes
Package Contents
  • SmartPro SMART1524ET 1500VA Rack-mountable UPS
  • External Battery Connection Kit
  • Battery Temperature Sensor Cable
  • USB Cable
  • External Fan Power Adapter Cable
  • 2 x AC Hardwire Strain Reliefs
  • 8 x M4 Screws
  • 4 x M6 Screws
  • 2 x Rack-Mounting Brackets
  • Instruction Sheet
  • Owner's Manual
Environmentally Friendly Yes
Environmental Certification RoHS
Network Management SNMP/Telnet/SSH
Alarm Battery Mode
Overload
Low Battery
UPS Fault
Application/Usage Edge Computing
Industry
Wind Power
Traffic Camera
Telecommunication
Surveillance System
Security System
Network Equipment
Network Closet
Military
Mission Critical Equipment
Overload Protection Yes
Plug/Connector Type Hardwired
Phase Single Phase
Receptacle Type Hardwired
EMI/RFI Noise Filter Yes
AVR Yes
Transfer Time 10 ms
Weight (Approximate) 14.70 kg
Form Factor Rack-mountable
Rack Height 3U
Height 5.24" (133 mm)
Width 15.75" (400 mm)
Depth 9.45" (240 mm)
Sound Emission 52 dB
Thermal Dissipation 266 BTU/h
Maximum Operating Temperature 176°F (80°C)
Maximum Operating Elevation 3280.84 ft (1000000 mm)
Storage Temperature -40°F (-40°C) - 176°F (80°C)
Environmental Sensors Contact Closure Sensor
Temperature Sensor
Input Voltage 120 V AC
Output Voltage 120 V AC
Load Capacity 1.50 kVA/1.20 kW
Surge Energy Rating 474 J
Waveform Type Pure Sine Wave
Output Frequency 60 Hz
Input Frequency 60 Hz
Product Type Line-interactive UPS
Manufacturer Part Number SMART1524ET
Manufacturer Website Address http://www.tripplite.com
Manufacturer Tripp Lite
Product Model SMART1524ET
Product Name SmartPro SMART1524ET 1500VA Rack-mountable UPS
Product Line SmartPro
Brand Name Tripp Lite
