Eaton Power-Sure 800 Line Conditioner - Lightning, AC Surge, Harmonics, AC Noise protection - Hardwired - 208 V AC, 240 V AC, 480 V AC Input - 10 kVA - 10 kW

EatonSKU: PL5-T800P-10000-44733W-EN
filler

Price:
Sale price$16,565.99

Description

Eaton Power-Sure 800 Line Conditioner - Lightning, AC Surge, Harmonics, AC Noise protection - Hardwired - 208 V AC, 240 V AC, 480 V AC Input - 10 kVA - 10 kW

Every facet of our daily life is being automated by faster microprocessors and microprocessor-based equipment which require steady continuous power. As market pressures force the deregulation of the electrical industry, utility companies have less and less control over the quality of power supplied to sensitive electronic equipment. In industry, the effects of unreliable power can be seen in the erroneous motion of computer-controlled milling machines, causing irreparable damage to expensive manufacturing equipment or finished products. Additionally, poor power quality can cause motor driven equipment to operate inefficiently and overheat, causing premature failure. In data processing and medical applications, the effects of unreliable power can be translated into incorrect data, lost memory, premature component failure, mixed and garbled data and inaccurate diagnostics. Power conditioning alleviates these problems.

Additional Information
    • Line Regulation: +/- 2% Vout for +10% to -20% Vin at 100% Load
    • Load Regulation: +/-3% for 0% to 100% load
    • Immunity to Distortion: @40% THD Vin, 5% Max THD Vout
    • Ride-through Capability: 1 cycle
    • Voltage Recovery: 2 cycles to 95%, 3 cycles to 100%
    • K-Factor: K-30 Rated
    • Power Factor Correction: Input of 0.95 typical
    • Harmonic Attenuation: -23dB for load reflected harmonics
    • Galvanic Isolation: NEC 250-5d, 0.001 pf
    • Surge Protection: UL 1449 Rating 330v; ANSI/IEEE C62.41-Cat B3
    • Common Mode Noise Attenuation: 140 dB
    • Transverse Mode Noise Attenuation: 120 dB
    • Reliability: 200,000 hours (MTBF)
    • Audible Noise: 1 meter A scale, 52dB to 56dB
    • Efficiency: Approx. 92% at full load
Limited Warranty 2 Year
Weight (Approximate) 243.58 kg
Height 28.50" (723.90 mm)
Width 27" (685.80 mm)
Depth 22.50" (571.50 mm)
Product Type Line Conditioner
Manufacturer Part Number T800P-10000
Manufacturer Website Address http://www.eaton.com/EatonCom/Markets/NorthAmerica
Manufacturer Eaton Corporation
Product Model T800P-10000
Product Name Power-Sure 800 Line Conditioner
Product Line Power-Sure
Brand Name Eaton
Protection Type Lightning
Harmonics
AC Surge
AC Noise
Plug/Connector Type Hardwired
Receptacle Type Hardwired
Input Voltage 208 V AC
240 V AC
480 V AC
Output Voltage 240 V AC
Maximum Frequency 50 Hz
Load Capacity (VA) 10 kW
Load Capacity (Watt) 10 kW
