Dual 300W Solar Panel - 60 Cell Utility Module - Anodized Aluminum Frame - Mounting Kit

LARSON ELECTRONICSSKU: PL3-SPK-PM-2X-300W
filler

Price:
Sale price$2,992.00

Description

Specifications / Additional Information
SPK-PM-2X-300W Dual 300W Solar Panels w/ Mounting Kit Certifications
Solar Cells: Monocrystalline 6 inches (156.75 x 156.75mm) UL 1703 Certified and Registered
Panel Dimensions: 64.9"L x 39.1"W x 1.38"H UL Module Fire Performance: Type 2
Cells Orientation (Per Panel): 60 Cells (6x10) CEC
Total Weight: 82 lb NEC2008 Compliant
Ambient Operating Temperature: -40°C to +85°C IEC 61215/61730
Maximum System Voltage: 1000V DC ISO 14001
Nominal Operating Cell Temperature (NOCT): 44°C High Performance Under Low Light Conditions
Temperature Coefficient of Pmax: - 0.40%/°C Locking Connectors for Easy and Fast Connections
Temperature Coefficient of Voc: - 0.31%/°C Can withstand 25mm hail stones @ 51mph
Temperature Coefficient of Isc: 0.06%/°C Mounting Kit Included
Peak Power Watts - PMAX (WP) (Per Panel): 300
Power Output Tolerance - PMAX (%) (Per Panel): 0 ~ +5
Maximum Power Voltage - VMP (V) (Per Panel): 32.2
Maximum Power Current - IMPP (A) (Per Panel): 9.33
Open Circuit Voltage - VOC (V) (Per Panel): 39.5
Short Circuit Current - ISC (A) (Per Panel): 9.84
Fuse Rating (Per Panel): 15 A
Module Materials: Andonized Aluminum, Black
Grounding: Grounding Points on Each Corner
Mounting: (4) Pole Clamps w/ Hardware
' Product Overview '
function MM_openBrWindow(theURL,winName,features) { //v2.0 window.open(theURL,winName,features); }
The SPK-PM-2X-300W from Larson Electronics is a pair of 300W Solar Panels that each feature a high output module designed for ground-mount installations that you can trust. The UV-stabilized anodized aluminum frame is easy to install with easily accessible grounding points on all four corners of the unit. Each module's 60-cell form factor is ideal for maintaining the lowest BOS costs where space is not a constraint. It is ideal for large scale installations and is certified to withstand challenging environmental conditions. *Please note: Any free shipping offers do not apply to this solar panel.* The SPK-PM-2X-300W features modules that offer the highest average output of any crystalline module. The unit's proven junction box technology has 12 AWG PV wiring and works with transformerless inverters. Locking plug-in connecters offer operators safe and quick connections. Mounting: This unit comes with a mounting kit that allows the panel to be secured on poles measuring 2" - 6" in diameter. The kit includes four pole clamps and hardware. Mounting rails attach to the back of the solar panel for stability. Pole clamps are used to secure the railing components holding the solar panel to the pole. Operators can adjust the angle of the panel by moving the bottom pole clamp up and down until the desired position is achieved. After adjustment, simply tighten the bolts and clamps to complete the installation.
