7.5HP VFD Phase Converter - 220-240V AC 1PH Input/3PH Output - 24 Amps - 5.5kW - NEMA 3R Rated

LARSON ELECTRONICSSKU: PL3-VFD-1P-220.240-3P-7.5HP-24A-DCM-N3R
filler

Price:
Sale price$5,784.00

Description

Specifications / Additional Information
VFD-1P-220.240-3P-7.5HP-24A-DCM-N3R Variable Frequency Device Features/Ratings
Unit Type: 1 Phase Input/3 Phase Output Delta, 3 Wire Variable Frequency Device Automatic Voltage Regulation
Dimensions: 13.34" x 9.09" x 8.42" LED Display
Weight: 24.2 lbs 1 Phase Input/3 Phase Output Delta, 3-Wire Configuration
Input/Output Voltage: 1 Phase 220-240V AC/3 Phase AC 0-Input Voltage Automatic Energy Save Running
Output Current: 24 Amps Automatic Current Limiting
Operating Frequency: 0 to 400 Hz NEMA 3R Rated Steel Panel Enclosure
Kilowatts: 5.5kw
HP: 7.5
Speed Regulation: 1:100
Speed Control Accuracy: =±0.5% of rating synchronous speed
Frequency Resolution: Analog setting: 0.1% of max frequency; Digital setting: 0.01Hz
Frequency Precision: Digital setting: 0.01% max, Analog Setting: Max frequency X 0.2% max
Torque boost: Automatic torque boost; manual torque boost: 0.1%~30.0%
Communication Terminal: RS485 communication interface
Control Mode: V/F Control; Sensorless Vector Control
Overload Capacity: 150% @ 60s, 180% @ 3s
Operating Temp: –10°C to +40°C
Max Operating Humidity: 95% (non condensing)
Materials: -
Mounting: NEMA 3R Rated Steel Panel
Color: Gray
' Product Overview '
The VFD-1P-220.240-3P-7.5HP-24A-DCM-N3R from Larson Electronics is a Single-Phase Input, 3 Phase Output, 3-Wire Configuration Variable Frequency Drive Phase Converter that is suitable for improving AC motor performance in industrial operations. This fan-cooled unit features a 220-240V AC input/output voltage comparability. Designed for steady speed error, fast torque rise and protection from resonance vibrations, the device provides an output current of 24 amps and an operating frequency range of 0 to 400 Hz with 7.5 horsepower. The VFD-1P-220.240-3P-7.5HP-24A-DCM-N3R is contained within a steel panel that is NEMA 3R rated. The VFD-1P-220.240-3P-7.5HP-24A-DCM-N3R offers accurate AC motor control in industrial facilities. This 5.5kw unit is compatible with single-phase input and three-phase output 220-240V AC voltage, provides an output current of 24 amps and an operating frequency range of 0 to 400 Hz. This device has a V/F control mode and sensorless vector control mode with an interior PID controlled, automatic energy save running to optimize the V/F curve, an automatic voltage regulator and automatic current limiting. The VFD-1P-220.240-3P-7.5HP-24A-DCM-N3R is designed for indoor applications and operating temperatures ranging between –10°C to +40°C. Operators may mount the VFD phase converter on compatible surfaces. This device measures 13.34" x 9.09" x 8.42" and weighs approximately 24 lbs. Mounting: The entire VFD-3P-380-60HP-91A-DCM-N3R-MOD1-N3R variable frequency drive is completely contained within a NEMA 3R rated steel panel. This 16 gauge steel panel enclosure features a drip on top and seam-free sides to protect against rain, snow, sleet, and other precipitation. The NEMA 3R panel also includes a hasp and staple for padlocking. The VFD-3P-380-60HP-91A-DCM-N3R-MOD1-N3R also includes a cooling fan mounted inside the panel to maintain correct airflow to the unit. Applications: Speed control of AC motors, industrial machines, large compressors, energy savings and more.
