Tripp Lite B127-008-H Video Extender Transmitter - 1 Input Device - 8 Output Device - 125 ft (38100 mm) Range - 8 x Network (RJ-45) - 1 x HDMI In - 4K UHD - 3840 x 2160 - Twisted Pair - Category 6 - Wall Mountable - TAA Compliant

Tripp LiteSKU: PL5-B127-008-H-755QQS-0037332253781-EN
filler

Price:
Sale price$638.99

Description

Tripp Lite B127-008-H Video Extender Transmitter - 1 Input Device - 8 Output Device - 125 ft (38100 mm) Range - 8 x Network (RJ-45) - 1 x HDMI In - 4K UHD - 3840 x 2160 - Twisted Pair - Category 6 - Wall Mountable - TAA Compliant

Features

Splitter Ideal for Digital Signage or Displaying Video in Schools or Trade Show Booths

This eight-port transmitter/splitter is recommended for video presentations in conference rooms, schools, trade shows, meeting facilities, houses of worship, retail settings and other digital signage applications where the source and display are farther apart than conventional A/V cables allow. The B127-008-H extends 4K video and stereo audio signals from an HDMI source device to eight HDMI displays up to 125 feet (38.1 meters) away via user-supplied Cat6 cabling.

Built-In PoC Technology Provides Power to Avoid Bulky External Power Bricks

Built-in Power over Cable (PoC) technology powers the connected B127-Series receivers over Cat6 cable. Green and orange LEDs will light up to indicate the unit is receiving power and a signal is being received. PoC lets you avoid the hassle of a bulky power brick and gives you the freedom to place the receivers away from an AC outlet.

Transmits Crystal-Clear 4K HDMI Video with Multi-Channel Audio and 4:4:4 Color

The B127-008-H supports Ultra HD video resolutions up to 3840 x 2160 (4K x 2K) at 60 Hz with full, rich uncompressed DTS-HD, Dolby TrueHD and 7.1-channel digital audio. The transmitter is compatible with HDMI 2.0 standards for carrying HDR signals, which provide a wide range of vibrant colors with richer contrast, brighter whites and deeper blacks. HDCP 2.2 compliance allows you to stream iTunes and Netflix content with no complications. The B127-008-H also supports 4:4:4 chroma subsampling for top-level PC gaming or using your HDTV as a PC monitor.

Daisy-Chain Multiple Transmitters to Add More Displays

An HDMI output is included for connecting up to three additional B127-008-H transmitters, each of which splits the original HDMI signal into eight. You can also connect an optional display to monitor the image connected to the receivers up to 125 feet away.

Plug-and-Play Operation for Quick Setup and Immediate Use

The included transmitter works right out of the box with no software required. Mounting hardware is included for installing the unit on a wall, pole or 19-inch rack. Connect the transmitter to the source with a user-supplied HDMI cable (such as Tripp Lite's P568- or P569-Series). Then, connect the transmitter to a Tripp Lite B127-100-H, B127-200-H or B127-100-H-SR remote receiver using Cat6 Ethernet cable (such as Tripp Lite N202-Series cable).

TAA-Compliant for GSA Schedule Purchases

The B127-008-H is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.

Typical Applications

  • Connect a media server, Blu-ray player, cable/satellite box, Roku, gaming system or other home theater component to 8 large-screen 4K televisions or projectors
  • Upgrade the video quality of your trade show presentation in a commercial or educational setting to 4K x 2K
  • Set up digital signage with a single video signal being transmitted to 8 monitors, each displaying its maximum resolution

System Requirements

  • Source device with DisplayPort output (Blu-ray player, cable box, laptop)
  • Tripp Lite B127-100-H, B127-200-H or B127-100-H-SR remote receivers
Features
  • Requires Tripp Lite B127-100-H, B127-200-H or B127-100-H-SR remote receiver
  • Maintains UHD resolutions up to 3840 x 2160 @ 60 Hz (4:4:4) for crystal-clear 4K video
  • Power over Cable (PoC) technology provides power to the receivers via Cat6 cable
  • Supports High Dynamic Range (HDR) for richer contrast and expanded color accuracy
  • Transmitter's local port shows you the UHD image being displayed up to 125 ft. away
  • 1-year limited warranty
Limited Warranty 1 Year
Twisted Pair Cable Standard Category 6
Media Type Supported Twisted Pair
Graphics Modes 4K UHD
Maximum Video Resolution 3840 x 2160
Number of Network (RJ-45) Ports 8
Network (RJ-45) Yes
Number of HDMI Inputs 1
HDMI In Yes
Product Type Video Extender Transmitter
Manufacturer Part Number B127-008-H
Manufacturer Website Address http://www.tripplite.com
Manufacturer Tripp Lite
Product Model B127-008-H
Product Name B127-008-H Video Extender Transmitter
Brand Name Tripp Lite
Package Contents
  • B127-008-H Video Extender Transmitter
  • External Power Supply with 4.5 ft. cord (Input: 100-240V, 50/60 Hz, 1.5A; Output: 24V 2A)
  • 4 x International plug adapters (North America, Europe, U.K. and Australia)
  • Mounting Hardware
  • Owner's Manual
Environmental Certification REACH
RoHS
TAA Compliant Yes
Connectivity Technology Wired
Maximum Operating Distance 125 ft (38100 mm)
Number of Output Devices Supported 8
Number of Input Devices Supported 1
Color Black
Form Factor Wall Mountable
Transmitter Height 1.17" (29.69 mm)
Transmitter Width 9.25" (235 mm)
Transmitter Depth 3.97" (100.84 mm)
