Super Micro Supermicro C2SBM-Q Desktop Motherboard - Intel Chipset - Socket T LGA-775 - Micro ATX - Core 2 Quad, Core 2 Duo, Celeron Dual-Core, Celeron Processor Supported - 8 GB DDR2 SDRAM Maximum RAM - DDR2-800/PC2-6400, DDR2-667/PC2-5300 - 4 x Memory

Save 16%
Super MicroSKU: PL5-MBD-C2SBM-Q-O-83668Z-EN
filler

Price:
Sale price$240.99 Regular price$286.64

Description

Supermicro C2SBM-Q Desktop Motherboard - Intel Chipset - Socket T LGA-775 - Micro ATX - Core 2 Quad, Core 2 Duo, Celeron Dual-Core, Celeron Processor Supported - 8 GB DDR2 SDRAM Maximum RAM - DDR2-800/PC2-6400, DDR2-667/PC2-5300 - 4 x Memory Slots - Gigabit Ethernet - 4 x SATA Interfaces

The C2SBM-Q Desktop Board is designed with the utmost attention to detail to provide you with the highest standards in quality and performance.

Gigabit Ethernet Yes
Sound Controller Manufacturer Realtek
Sound Controller Model ALC 883
Audio Channels 7.1
Form Factor Micro ATX
Width 9.60" (243.84 mm)
Depth 9.60" (243.84 mm)
Additional Information

    Chipset:

    • North Bridge : Intel Q35
    • South Bridge : Intel ICH9DO

    System BIOS:

    • BIOS Type:
    • 16Mb SPI Flash EEPROM with Phoenix BIOS
    • BIOS Features:
    • Plug and Play (PnP)
    • DMI 2.3
    • PCI 2.2
    • ACPI 1.0 / 2.0
    • USB Keyboard support
    • SMBIOS 2.3

    Management:

    • Software:
    • Super Doctor III
    • Watch Dog
    • NMI
    • Power Configurations:
    • ACPI/APM Power Management
    • Main Switch Override Mechanism
    • Wake-On-Ring (WOR) header
    • Wake-On-LAN (WOL) header
    • Keyboard Wakeup from Soft-Off
    • Power-on mode control for AC power recovery
    • Internal / External modem remote ring-on
    • Suspend to RAM (STR)

    PC Health Monitoring:

    • CPU:
    • Monitors for CPU Cores, +1.8V, +3.3V, +5V, ±12V, +3.3V/+5V Standby, VBAT, HT, Memory, Chipset
    • CPU Core 3-Phase-switching voltage regulator with auto-sense from 0.8375V-1.6000V
    • Adjustable CPU clock frequency ratio
    • FAN:
    • Total of three 4-pin fan headers
    • 3 x fans with tachometer monitoring
    • Status monitor for speed control
    • Status monitor for on / off control
    • Support 3-pin PWM fans (without speed control)
    • Low noise fan speed control
    • Pulse Width Modulated (PWM) fan conn.
    • Temperature:
    • Monitoring for CPU and chassis environment
    • CPU thermal trip support
    • Thermal Monitor 2 (TM2) Support
    • PECI
Package Contents
  • C2SBM-Q Desktop Board
  • 1 x ATA 66/100 IDE LP Cable
  • 4 x SATA Cable (2Ft.)
  • 1 x CD
  • 1 x I/O Shield
  • Motherboard Manual
Environmentally Friendly Yes
Environmental Certification RoHS
Number of PCI Slots 2
Number of Total Expansion Slots 4
Number of PCI Express x8 Slots 1
Number of PCI Express x16 Slots 1
Total Number of PCI Express Slots 2
Number of IDE Interfaces 1
Number of SATA Interfaces 4
Total Number of Onboard USB Ports 2
Onboard LEDs Header Yes
Onboard Audio Header Yes
Processor Supported Core 2 Quad
Core 2 Duo
Celeron Dual-Core
Celeron
Total Processor Supported 1
Processor Socket Socket T LGA-775
Processor Technology Enhanced SpeedStep Technology
Front Side Bus 800 MHz
1333 MHz
1066 MHz
64-bit Processing Yes
Chipset Manufacturer Intel
Maximum Memory Supported 8 GB
Memory Technology DDR2 SDRAM
Memory Standard DDR2-800/PC2-6400
DDR2-667/PC2-5300
Number of Memory Slots 4
Memory Speed Supported 800 MHz
667 MHz
Product Type Desktop Motherboard
Manufacturer Part Number MBD-C2SBM-Q-O
Manufacturer Website Address http://www.supermicro.com
Manufacturer Supermicro Computer, Inc
Product Model C2SBM-Q
Product Name C2SBM-Q Desktop Motherboard
Package Type Retail
Brand Name Supermicro
RAID Levels 1
1+0
5
0
Controller Type Serial ATA/300
Ultra ATA/100 (ATA-6)
Floppy Controller
RAID Supported Yes
VGA Yes
Network (RJ-45) Yes
Audio Line In Yes
Audio Line Out Yes
Serial Port Yes
Microphone Port Yes
Total Number of USB Ports 6
Number of USB 2.0 Ports 6
