Super Micro Supermicro C7H61-L Desktop Motherboard - Intel Chipset - Socket H2 LGA-1155 - ATX - 16 GB DDR3 SDRAM Maximum RAM - 2 x Memory Slots - Gigabit Ethernet - HDMI - DisplayPort - 6 x SATA Interfaces

Super MicroSKU: PL5-MBD-C7H61-L-O-83642Z-EN
filler

Price:
Sale price$219.99

Description

Supermicro C7H61-L Desktop Motherboard - Intel Chipset - Socket H2 LGA-1155 - ATX - 16 GB DDR3 SDRAM Maximum RAM - 2 x Memory Slots - Gigabit Ethernet - HDMI - DisplayPort - 6 x SATA Interfaces

B75/H61 Chipset / Socket H2 (LGA 1155) Boards

Supermicro motherboards based on the Intel 2nd and 3rd Generation Core? i7/i5/i3 processor series and Intel B75/H61 chipset. With features that include PCI-E 3.0 slot(s), DDR3 memory, LAN port(s), SATA3 ports, multiple USB ports, integrated audio, and TPM header ready, these boards are Supermicro's latest premium desktop motherboards that demonstrate huge leaps in quality, performance, and visual processing capabilities.
Gigabit Ethernet Yes
Sound Controller Manufacturer Realtek
Sound Controller Model ALC888S-VD2
Controller Type Serial ATA/600
Serial ATA/300
Certifications & Standards
    • ACPI 2.0
Environmentally Friendly Yes
Environmental Certification RoHS-6
Form Factor ATX
Width 12.01" (305 mm)
Depth 9.61" (244 mm)
Number of SATA Interfaces 6
Total Number of Onboard USB Ports 4
Number of Onboard USB 2.0 Ports 4
Onboard LEDs Header Yes
Onboard Audio Header Yes
Number of PCI Slots 5
Number of PCI Express x1 Slots 1
Number of Total Expansion Slots 7
Number of PCI Express x16 Slots 1
PCI Express Standard PCI Express 2.0
PCI Express 3.0
Total Number of PCI Express Slots 2
Product Type Desktop Motherboard
Manufacturer Part Number MBD-C7H61-L-O
Manufacturer Website Address http://www.supermicro.com
Manufacturer Supermicro Computer, Inc
Product Model C7H61-L
Product Name C7H61-L Desktop Motherboard
Package Type Retail
Brand Name Supermicro
Maximum Memory Supported 16 GB
Memory Technology DDR3 SDRAM
Memory Standard DDR3-1333/PC3-10600
DDR3-1600/PC3-12800
Number of Memory Slots 2
Memory Form Factor DIMM
UDIMM
Memory Speed Supported 1333 MHz
1600 MHz
Processor Supported Core i3
Core i5
Core i7
Pentium
Celeron
Total Processor Supported 1
Processor Socket Socket H2 LGA-1155
64-bit Processing Yes
Chipset Manufacturer Intel
S/PDIF Yes
HDMI Yes
Number of Network (RJ-45) Ports 2
Network (RJ-45) Yes
Audio Line In Yes
Audio Line Out Yes
DisplayPort Yes
Serial Port Yes
Microphone Port Yes
Total Number of USB Ports 6
Number of USB 2.0 Ports 6
