Super Micro Supermicro PDSLE Desktop Motherboard - Intel Chipset - Socket T LGA-775 - Pentium 4, Pentium 4 (Extreme Edition), Pentium D, Celeron D Processor Supported - 4 GB DDR2 SDRAM Maximum RAM - DDR2-400/PC2-3200, DDR2-533/PC2-4200, DDR2-667/PC2-5300

Save 24%
Super MicroSKU: PL5-MBD-PDSLE-O-83685Z-EN
filler

Price:
Sale price$209.99 Regular price$275.76

Description

Supermicro PDSLE Desktop Motherboard - Intel Chipset - Socket T LGA-775 - Pentium 4, Pentium 4 (Extreme Edition), Pentium D, Celeron D Processor Supported - 4 GB DDR2 SDRAM Maximum RAM - DDR2-400/PC2-3200, DDR2-533/PC2-4200, DDR2-667/PC2-5300 - 4 x Memory Slots - Gigabit Ethernet - 4 x SATA Interfaces

Major Benefits from Supermicro's in-house Design Superiority

Supermicro motherboard advantages:

  • Technologically-advanced Motherboard Designs Since 1993
  • Consistent highest-quality Design, Components, and Production Expertise
  • Extensive Range of x86 Serverboards Available
  • Competitive Price/Performance
  • High Performance Boards Supporting the Latest CPU, memory, and add-on Hardware
  • Standard Form Factors offer Feature - rich Support and application optimization

These competitive advantages help Supermicro maintain its design leadership in providing state-of-the-art motherboards for a wide range of applications. Always a step ahead of the competition, Supermicro is consistently first-to-market in delivering high-performance technology support. Offering the most extensive serverboard selection in the industry at competitive prices, Supermicro boards are quality-built to maximize customer satisfaction.

Gigabit Ethernet Yes
Limited Warranty 3 Year
Sound Controller Model AC'97
Audio Channels 5.1
Additional Information

    Chipset:

    • Intel's 945P chipset consists of two primary components:
    • The Memory Controller Hub (MCH)
    • The I/O Controller Hub (ICH7)

    Memory Controller Hub:

    • Supports a FSB frequency of 533/800/1066 MHz using a scalable CPU
    • Supports up to two channels of non-ECC DDR2 400/533/667 SDRAM
    • Supports advanced desktop power management
    • Manage the data fl ow of the following interfaces:
    • CPU interface
    • DDR2 interface
    • PCI Express Graphic Interface
    • DMI (Direct Media Interface)

    I/O Controller Hub (ICH7):

    • Provides extensive I/O support to a high-end 945P system, functions and capabilities include:
    • PCI Express Base Specification, Rev. 1.0a-compliant
    • PCI 2.3 with support for 33 MHz PCI operations
    • ACPI Power Management Logic Support
    • Integrated IDE controller supports Ultra ATA 100/66/33
    • USB host interface with support for eight USB ports
    • Enhanced DMA Controller, interrupt controller, and timer functions
    • System Management Bus (SM Bus) 2.0 with additional support for I2C devices
    • Low Pin Count (LPC) Interface
    • Firmware Hub (FWH) Interface
    • Audio Codec '97 Rev. 2.3 which provides a link for Audio (up to 6 channels)
    • Integrated Serial ATA host controller with independent DMA operation on four ports, with support of SATA I and SATA II HDD)

    PCI-Express Slots:

    • 1 (x16) PCI-e slot (intended for Graphics applications)
    • 2 (x1) PCI-e slots, (one using x8 slot)
Package Contents
  • 1 x PDSLE Desktop Board
  • 1 x ATX Floppy Cable
  • 1 x ATA 66/100 IDE LP Cable
  • 1 x SATA Cable (2Ft.)
  • 1 x Version 1.10 (or newer) CD
  • 1 x Motherboard Manual
  • 1 x I/O Shield for PDSLE
Width 11.50" (292.10 mm)
Depth 9.50" (241.30 mm)
Controller Type Ultra ATA/100 (ATA-6)
Serial ATA/300
Floppy Controller
Number of IDE Interfaces 1
Number of SATA Interfaces 4
Total Number of Onboard USB Ports 2
Onboard LEDs Header Yes
Onboard Audio Header Yes
Number of PCI Slots 4
Number of PCI Express x1 Slots 1
Number of Total Expansion Slots 7
Number of PCI Express x8 Slots 1
Number of PCI Express x16 Slots 1
Total Number of PCI Express Slots 3
Processor Supported Pentium 4 (Extreme Edition)
Pentium 4
Celeron D
Pentium D
Total Processor Supported 1
Processor Socket Socket T LGA-775
Chipset Manufacturer Intel
VGA Yes
Network (RJ-45) Yes
Audio Line In Yes
Audio Line Out Yes
Serial Port Yes
Parallel Port Yes
Microphone Port Yes
Total Number of USB Ports 6
Number of USB 2.0 Ports 6
Maximum Memory Supported 4 GB
Memory Technology DDR2 SDRAM
Memory Standard DDR2-667/PC2-5300
DDR2-533/PC2-4200
DDR2-400/PC2-3200
Number of Memory Slots 4
Memory Speed Supported 533 MHz
400 MHz
667 MHz
Product Type Desktop Motherboard
Manufacturer Part Number MBD-PDSLE-O
Manufacturer Website Address http://www.supermicro.com
Packaged Quantity 1
Manufacturer Supermicro Computer, Inc
Product Model PDSLE
Product Name PDSLE Desktop Motherboard
Package Type Retail
Brand Name Supermicro
Packing Box
