Tripp Lite Switched Metered PDUMH20NET 16-Outlets PDU - Switched - NEMA L5-20P - 16 x NEMA 5-15/20R - 120 V AC - 1U - Vertical - Rack-mountable, Wall-mountable

Tripp LiteSKU: PL5-PDUMH20NET-52839R-0037332157683-EN
filler

Price:
Sale price$1,266.99

Description

Tripp Lite Switched Metered PDUMH20NET 16-Outlets PDU - Switched - NEMA L5-20P - 16 x NEMA 5-15/20R - 120 V AC - 1U - Vertical - Rack-mountable, Wall-mountable

Tripp Lite single phase Switched PDU / Power Distribution Unit offers advanced network control and monitoring with the ability to turn on, turn off, recycle or lock-out power to each individual receptacle, monitor site electrical conditions and remotely monitor output power consumption. The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP, BOOTP and NTP. Individually switched outlets can be controlled in real-time to remotely reboot unresponsive network hardware, or be custom programmed for user-defined power-up and power-down sequences to ensure proper startup of interdependent IT systems and prevent inrush-related overloads as network equipment is first energized. Unused PDU outlets can be electronically locked off to prevent the connection of unauthorized hardware. PDU output current consumption in amps is continuously displayed locally via visual meter and remotely via web/network interface to warn of potential overloads before critical IT mains or branch breakers trip.
Features
  • Switched 20A 120V PDU, 1U horizontal rackmount format
  • Reports voltage, frequency & load level via ethernet interface
  • Visual current meter, Reversible housing
  • NEMA L5-20P input with 5-20P plug adapter, 12 ft. / 3.6m line cord
  • 16 NEMA 5-15/20R switched outlets with cord retention brackets
  • Temperature, humidity and contact closure monitoring options
  • TAA Compliant
Management

    Protocols:

    • HTTP
    • HTTPS
    • SMTP
    • SNMPv1
    • SNMPv2
    • Telnet
    • FTP
    • DHCP
    • BOOTP
    • NTP
Limited Warranty 2 Year
Input Voltage 120 V AC
Output Voltage 120 V AC
Package Contents
  • Switched Metered PDUMH20NET 16-Outlets PDU
  • L5-20P Input Power Cord
  • 5-20P Plug Adapter
  • Installable 1U Mounting Brackets
  • PowerAlert Software
  • User Manual
Country of Origin Taiwan
Environmentally Friendly Yes
Environmental Certification RoHS
Product Type PDU
Manufacturer Part Number PDUMH20NET
Manufacturer Website Address http://www.tripplite.com
Manufacturer Tripp Lite
Product Model PDUMH20NET
Product Name Switched Metered PDUMH20NET 16-Outlets PDU
Product Series Switched Metered
Brand Name Tripp Lite
Plug/Connector Type NEMA L5-20P
Receptacle Type NEMA 5-15/20R
PDU Type Switched
Receptacle Detail 16 x NEMA 5-15/20R
Weight (Approximate) 5.67 kg
Mount Type Rack-mountable
Wall-mountable
Rack Height 1U
Height 1.75" (44.45 mm)
Width 17.50" (444.50 mm)
Depth 15.50" (393.70 mm)
Mounting Orientation Vertical
