Flameproof Isolator/Disconnect Switch - 16A MCB - 480V, 2P - Aluminum - (2) 3/4" NPT - ATEX - (1) NO & (1) NC Auxiliary Contacts

LARSON ELECTRONICSSKU: PL3-ATEX-EPNFDS-16A-2P-AUX.2C
filler

Precio:
Precio de venta$1,000.00

Descripción

Specifications / Additional Information
ATEX-EPNFDS-16A-2P-AUX.2C Explosion Proof Disconnect Switch w/ (2) Auxiliary Contacts Ratings
Listing: European Union, International ATEX Rated
Dimensions: 11.81" x 13.18" x 4.72" (200mm x 335mm x 120mm) Ex de IIB T4 Gb
Weight: - Ex tD A21 IP54 T80°C
Maximum Voltage: 480V AC Cable Gland Not Included
Poles: 3
Amp Rating: 16A Rated MCB
Switching Mechanism: Rotary Knob
Materials: Aluminum
Mounting: Surface Mount Special Orders - Requirements
Hub Qty: 2
Hub Sizes: (2) 3/4" NPT
Hub Locations: (2) Bottom
Cable Glands: NA
Auxiliary Contacts: (2) Auxiliary Contacts - (1) Normally Open & (1) Normally Closed
*All grounding shall comply with state and local codes and meet the minimum requirements of the National Electronic Code section 250*
' Product Overview '
The ATEX-EPNFDS-16A-2P-AUX.2C from Larson Electronics is a Flameproof Isolator/Disconnect Switch that is designed for use in ATEX rated explosive sites. Compatible with 480V AC (maximum), this IP54rated device features a 16-amp main circuit breaker. The surface-mount flameproof accessory contains two, 3/4" NPT hubs and requires customer-provided cable glands during installation. The ATEX-EPNFDS-16A-2P-AUX.2C is equipped with (2) auxiliary contacts. *PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO EXPLOSION PROOF ENCLOSURES* The ATEX-EPNFDS-16A-2P-AUX.2C provides protection for electrical connections and systems in combustible facilities. The 2-pole flameproof isolator switch contains a 16-amp rated main circuit breaker and is compatible with 480V (maximum). During use, a rotary knob on the unit facilitates disconnection. This explosion proof device is constructed of aluminum. Equipped with a T4 temperature rating, the disconnect switch is IP54rated waterproof and suitable for ATEX rated environments. Wiring: The flameproof isolator features two, 3/4" NPT hubs for completing wiring/electrical connections. Both 3/4" NPT hubs are located at the bottom of the unit. Cable glands are not included with this model and must be supplied by the customer. Auxiliary Contacts: The ATEX-EPNFDS-16A-2P-AUX.2C is equipped with (1) normally open auxiliary contact and (1) normally closed auxiliary contact for a total of (2) auxiliary contacts. Mount: Operators can mount the explosion proof device on flat surfaces. Applications: Petroleum refineries, chemical and petrochemical plants, storage areas, and other processing facilities where hazardous substances are handled or stored.
