Waterproof Transformer Converts 120V-277V AC (Wall Outlet) to 42 Volts DC - 5.72 Amps Max

LARSON ELECTRONICSSKU: PL3-DCP-16-42V
filler

Precio:
Precio de venta$618.00
 Más opciones de pago

Descripción

Specifications / Additional Information
DCP-16-42V Power Converter DCP-16-42V Features
Line In Voltage: 120-277V AC @ 47~63 Hz IP67 Rated Waterproof
Line Out: 42VDC @ 5.72 Amps Overload,Short Circuit, Over Voltage Protection
Watts: 240W Max; 192W Continuous UL1012 Compliant
AC Input Connector: 1` Pigtail, Stripped/Tinned Leads UL60950-1 Compliant
DC Output Connector: 1` Pigtail, Stripped/Tinned Leads International Lighting Safety Standards Compliant
Protection: Short Circuit/Overload/ Over Voltage Suitable For LED Moving Signs
Mounting: Two Screw Slide Notches
Operating Temp: -30°C to +70°C
Efficiency: 92%
Dimensions: 8.7"L x 2.5"W x 1.5"D Toll Free: 1-800-369-6671
Weight: 1 Lbs Intl: 1-214-616-6180
  Fax: 1-903-498-3364
  E-mail:
' Product Overview '
The DCP-16-42V from Larson Electronics is a Waterproof Power Supply that converts commonly used 120-277V AC electrical current to 42V DC @ 5.72 Amps. This converter is designed to be hardwired into home, boat or vehicle electrical supplies where the voltage is typically within the 120-277V AC range and reduces it to 42V DC, allowing users to use standard AC power to operate equipment like our LED light bars and HID Golights that require 42 Volt DC current. The DCP-16-42V 240 watt max (192 watt continuous) power converter provides a safe and effective way for users to tap into and utilize common 120 to 277 Volt AC power sources and convert this current to 42 Volts DC at 5.72 amps for use with equipment that requires 42V DC electrical power. This unit can be operated with input current ranging from 120 to 277V AC and will output 240 watts max (192 watts continuous) at 5.72 amps on a 42 Volt DC current. This power converter features an IP67 rated waterproof design, making it suitable for indoor or outdoor use and includes integral short circuit and overload protection that will shut down the unit in case of faults and overloads to protect the unit and connected equipment from damage.
The small size and wide input voltage range of this unit make it ideal for operating Larson Electronics LED light bars, Golights and other equipment that requires 42V DC current indoors or outdoors and anywhere 42 volt DC power is not readily available. Measuring 8.7 inches long by 2.5 inches wide by 1.5 inches deep, this unit weighs less than one pound and is mounted with two conventional screws via slots that allow removal and repositioning simply by loosening the screws. This converter comes with clearly labeled input and output leads that are approximately 1 foot long and stripped and tinned for hardwired connections using butt splice connectors, wire screws, plates, etc. The DCP-16-42V 240 watt max (192 watt continuous) converter features full range, universal AC input capability and can be operated with 120 to 277V AC. The unit converts this AC power input to 240 watts max or 192 watts continuous, 5.72 Amp 42V DC. IP67 rated, this unit is waterproof and suitable for indoor or outdoor applications. Integrally designed protection includes overload, short circuit and over voltage safeguards to prevent overheating and unit damage in case of faults or overly heavy current draw. This unit will limit current when an over current condition is encountered and recovers when the condition is removed. This unit will enter hiccup mode under short circuit conditions and recover when the fault is removed. The unit will also shut down when an over temperature condition occurs and recovers automatically when the temperature returns to normal levels. This power converter has a -30°C / +60°C operating temperature range and is UL UL1012 and UL60950-1 compliant as well as compliant with worldwide safety regulations for lighting. This unit has a 90% conversion efficiency and is suitable for use with moving LED signs and similar LED equipment. These units also feature Power Factor Correction, adjustable output current range from 8~ 16A either through the output cable or internal potential meter and have an input frequency range of 47 ~ 63Hz. NOTE: In order to obtain the best performance and the longest operational life from these units, it is recommended that you do not exceed 75% of the unit`s output amperage. To determine if this converter suits your desired application, add together the total wattage of the equipment you intend to use with this unit and divide this total by 12 volts to find the total amperage draw that will be placed upon the converter. For example, if you are using two of our LEDP10W-120E 120 watt LED lights, 120 watts divided by 42 volts is 2.86 amps. This would mean the DCP-16-42V is well suited as it would run at under 50% capacity to produce the necessary 2.86 amps. Running these units at 100% of their capacity can create excess heat and lead to shortened converter life.
