Larson Explosion Proof Extension Cord - 166 Feet - 14 Gauge SOOW Cord - Inline Switch

Larson ElectronicsSKU: PL3-EPEXC-166-ILS
filler

Precio:
Precio de venta$4,384.00
 Más opciones de pago

Descripción

PuriLite suggests you place an order directly with us for large Larson orders due to the potential customization requirements. Please call us at 1(647) 254-9757 to place your order. If you prefer to place your order online, a PuriLite agent will be in touch with you to discuss any custom options.
Made in the USA
The Larson Electronics EPEXC-166-ILS Explosion Proof extension cord with inline switch allows operators to safely extend the range of their explosion proof light or equipment cords beyond the boundaries of the hazardous work area.
These units are constructed of 166 feet of 14/3 SOOW explosion proof cord and are rated at 15 amps of continuous service. The cord is chemical and abrasion resistant and comes with a Class 1 Division 1 explosion proof receptacle and switch installed on one end and a Class 1 Division 1 explosion proof plug installed on the other end. We also include an extra matching plug for operators to attach to their equipment which allows them to avoid any issues with plug and receptacle equipment compatibility with this cord.
5-15P Explosion Proof Straight Blade Plug
125V 5-15/20 Explosion Proof Outlet
Outlet accepts 5-15P and 5-20P Explosion Proof Plugs
The plugs on these units are of a twist lock design. In order for a secure and working connection to take place, the operator must insert the plug and twist until it locks into place. This ensures a safe seal is made before any sparks from electrical contact can take place. Explosion proof lights, blowers and fans typically do not contain their own on and off switches and are plugged in some distance from the hazardous work area, forcing operators to walk some distance out of the work area to turn this equipment on or off. This unit includes an inline switch which allows operators to leave the cords plugged in and switch equipment on or off within the hazardous work area. This switch also allows operators to safely connect and disconnect equipment downline of the switch simply by turning off the switch before changing connections. To remove all risk and retain the highest level of protection, operators should make all connections outside of the hazardous work area.
Inter-Compatibility:
These cords will work with non-explosion proof standard receptacles (NEMA 5-15R, 5-20R, or 6-20R). The included plugs and receptacle are cross-interchangeable with Crouse Hindâ„¢ part# ENPENP5151 plugs and receptacles and Hubble-Killiark part# UGP-15231 ACCEPTOR plugs and receptacles. Any equipment requiring these C-H or H-B plugs should work with these cords. Due to possible manufacturer changes we cannot guarantee interchangability although we have made every effort to ensure cross compatibility correctness.
Suggested Applications:
Manufacturing, Industrial, Warehouse, Lighting, Explosion Proof Light Fixtures, Wet areas or Locations Where Combustible Dust is Present.

Specifications
Amp Rating: 15 amp Continuous Service
Dimensions: Cord length-166 Feet Plug-2.78"-L 1.75"-W 3"-W X 5.69"-D X6.13"-H 3"-W X 4.69"-D X 5.38"-H
Configuration: 2 Pole 3 Wire 2 Pole 3 Wire Front Mounted Switch
Suitable Plug Cable Diameter: .538” to .639”
Wiring: 166` 14/3 SOOW Cable Terminated w/ (1) 20 Amp Receptacle and In-Line Switch - (1) 5-15P Explosion Proof Straight Blade Plug
Voltage: 125 Volts
Receptacle Specs: 1 In-Line Receptacle
Configuration: 2 Pole 3 Wire 2 Pole 3 Wire Front Mounted Switch

Materials: Copper Free Aluminum Malleable Iron - Copper Free Aluminum
Dimensions: Cord length-166 Feet Plug-2.78"-L 1.75"-W 3"-W X 5.69"-D X6.13"-H 3"-W X 4.69"-D X 5.38"-H
Mating Plugs: ****EPP-15A, EPP-20-A****
Finish: Epoxy Powder Coat Triple-Coat—(1) zinc electroplate, (2) chromate, (3) epoxy powder coat

Switch Specs:
Configuration: 2 Pole 3 Wire 2 Pole 3 Wire Front Mounted Switch

Materials: Copper Free Aluminum Malleable Iron - Copper Free Aluminum
Dimensions: Cord length-166 Feet Plug-2.78"-L 1.75"-W 3"-W X 5.69"-D X6.13"-H 3"-W X 4.69"-D X 5.38"-H
Finish: Epoxy Powder Coat Triple-Coat—(1) zinc electroplate, (2) chromate, (3) epoxy powder coat
