Integrated Explosion Proof LED Paint Spray Booth Light - Class 1 Div 1 - Class 1 Div 2 - 8,000 Lumen - Pendant and Surface Mount

LARSON ELECTRONICSSKU: PL3-EPL-48-2L-ITG-LED-PNSF
filler

Precio:
Precio de venta$2,910.00

Descripción

Specifications / Additional Information
EPL-48-2L-ITG-LED-PNSF Explosion Proof LED Fixture Ratings/Approvals
NRTL Listed for United States & Canada Class I Division 1, Groups C and D T6
Dimensions: 52.00"-L x 11.25"-W x 8.50"-H Class I Division 2, Group A,B,C,D
Weight: 55 lb Class II, Divisions 1 & 2, Groups E,F,G
Voltage: Universal 120-277 V AC, 50/60 Hz or 11-25 V AC/DC NRTL Certified to UL 595 Marine Type (Saltwater)
Total Watts: 80 Watts NRTL Certified to UL 844
Total Lumens: 8,000 NRTL Certified to UL 1598 Marine Type
LED Lamp Life Expectancy: 50,000+ Hours Certified Canadian Standards
Luminous Efficiency: 100 Lumens per Watt Listed for Paint Spray Booths
Color Temp: 5000K, 4500K, 4000K, 3500K, 3000K, or 2700K California Title 24 Compliant
Color Rendering Index: >80 IP67 Rated - Waterproof
Beam Angle: 150° T6 Temperature Rating
Power Efficiency: 90% NEMA 4X
Power Factor: >0.95 LEL Listed LED Lamps
Ambient Operating Temp Range: -30°C to +85°C Approved for Confined Spares
Operating Temp Rating: T6 Rated Silicone Free
Minimum Operating Temp: -30°C Factory Sealed Fixture
Maximum Case Temp: +90°C Individually Dimmable Lamps
Housing Material: Cast Aluminum End Caps, Aluminum Reflectors - Copper Free Made in the USA
Lens Material: Hardened Borosilicate Glass Tubes
Gasket Material: Buna Rubber O-Rings Special Orders - Requirements
Mounting: Surface Mount or Pendant Mount (Both Bracket Styles Included)
Wiring Hub: 1/2" NPT Toll Free: 1-800-369-6671
  Intl: 1-214-616-6180
Fax: 1-903-498-3364
  E-mail:
' Product Overview '
Made in the USA The EPL-48-2L-ITG-LED-PNSF from Larson Electronics is an Explosion Proof Integrated LED Light Fixture that is NRTL Listed for United States and Canada and rated Class I Divisions 1 & 2 and Class II Divisions 1 and 2 for areas where flammable chemical/petrochemical vapors exist or have the potential to exist. This integrated explosion proof LED light has a T6 temperature rating and carries a paint spray booth light certification, making it ideal for applications such as paint booths, oil rigs, offshore applications, petrochemical, manufacturing, chemical storage, water treatment centers, and food processing plants. This four foot, two lamp integrated LED fixture is ideal for operators seeking a top quality explosion proof LED light that will reduce operating costs, improve lighting quality and reduce downtime incurred from frequent servicing intervals. The EPL-48-2L-ITG-LED-PNSF is equipped with a specially designed integrated LED assembly which produce 8,000 lumens, resulting in 50% more foot candles of illumination at 8 feet as compared to standard T5HO lamps when measured with an Extech light meter. Our integrated series are visibly brighter than standard T5HO's and have consistently surprised many of our customers with their unexpectedly high light output levels. We now offer our first generation integrated LED tube assembly within this fixture which have increased this hazardous location light's performance. This two lamp explosion proof LED linear fixture is lighter in weight and produces more light than traditional explosion proof fluorescent fixtures. The four foot long LED tube design bulbs included with this unit are rated at 50,000 hours of service life, which is over twice as long as standard T5HO bulbs. These lamps are individually dimmable via Mark 7 0-10 V style dimmer switches for maximum control over illumination levels. This fixture carries a T6 temperature rating and is approved for Class I Division 1, Groups C and D, Class I, Division 2, Group A, B, C and D, and Class II, Divisions 1 and 2, Groups E, F and G environments where flammable or combustible gases, vapors, dusts, fibers, and flying exist or stand the potential to exist. This LED linear fixture is approved for use in confined spaces.
Click Image to Enlarge Click Image to Enlarge Click Image to Enlarge
Unlike the glass tube design of traditional fluorescent lamps, these integrated LED fixtures have no filaments or fragile housings to break during operation. Instead of using a combination of gases to produce light, light emitting diodes (LEDs) use semi-conductive materials that illuminate when electric current applied and emitting light. The LED assembly is mounted to the "tube" constructed from extruded aluminum, with a polycarbonate lens protecting the LEDs. With LED lights, there is no warm up time or cool down time before re-striking and provide instant illumination when powered on, adding to the reliability of LED technology. By nature, LED light sources run significantly cooler than fluorescent lamps, reducing the chance of accidental burns and increased temperatures due to heat emissions. This solid state design of light emitting diodes provides a more reliable, stable, durable, and energy efficient light source over traditional fluorescent lighting. The dual 40 watt LED assemblies produce 50% more illumination than standard T5HO bulbs while offering lower amp draw and increased reliability. Each lamp produces 4,000 lumens at 100 lumens per watt, for a combined 8,000 total lumen light output. An EPL-48-2L-T5HO explosion proof fluorescent light, with a combined total of 104 watts, draws 0.87 amps at 120 volts AC. This LED version of the same light, with a total of 80 watts, draws only 0.67 amps at 120 volts AC. The EPL-48-2L-ITG-LED-PNSF is universal voltage, not multi-tap, and operates on any voltage from 120V to 277 V AC, 50/60 Hz without any modifications. We also make a 12/24 V AC/DC version for low voltage applications for AC or DC power.
Energy Consumption Comparison
T5HO T8 LED
Wattage 108 watts 64 watts 80 watts
Amp Draw @ 120 V AC 0.90 amps 0.54 amps 0.67 amps
Amp Draw @ 220 V AC 0.49 amps 0.29 amps 0.36 amps
Amp Draw @ 240 V AC 0.45 amps 0.27 amps 0.33 amps
Amp Draw @ 277 V AC 0.39 amps 0.24 amps 0.29 amps
Amp Draw @ 12 V DC 9 amps 5.34 amps 6.67 amps
Amp Draw @ 24 V DC 4.5 amps 2.67 amps 3.34 amps
Lamp Life Expectancy 20,000 hours 24,000 hours 50,000 hours
Operation cost per year (12hs/day @ 12c/kWh) $56.77 $33.64 $42.04
Our EPL-48-2L-ITG-LED-PNSF LED light fixture is NRTL Listed for United States and Canada and approved for use in paint spray booths. Please note, according to the NEC, using threaded rigid pipe does not require additional seal offs with this fixture. An EYM and seal off is necessary for flex conduit or other non-rigid pipe implementations. Mounting Options: The EPL-48-2L-ITG-LED-PNSF is shipped with both surface mount brackets and pendant mount brackets. The surface mount brackets come preinstalled on the fixture while the pendant mount brackets are separate. This gives operators the option of choosing which mounting method works best for their needs and the requirements of the mounting area. It also allows operators to switch mounting methods when moving the light or making other adjustments. Adjustable Surface Mount Brackets: Each bracket is cinched to the bracket mounting peg on each side of the light. The angle of the bracket is set by tightening two cap screws on either side of the bracket. The cap screws act as a set screw. The bracket itself is mounted via a single bolt hole at the top the bracket. There are two brackets, one on each end of the light. Once the brackets are mounted to a surface (ceiling, floor or wall), the light fixture can be removed from the brackets by loosening the cap screws that hold the bracket to the mounting peg. Suspension Mounting: Pendant mount fixtures hang from the ceiling and are suspended by rigid pipe. Each fixture features a 1/2" NPT junction box on one end, and a 1/2" NPT adjustable L-bracket on the other end of the fixture. Operators bring rigid pipe down to the threaded mounting hubs. Wiring is fed down through the rigid pipe to the junction box and tied in to the fixture€™s lead wires, completing the electrical connection. The adjustable L-shape mounting bracket provides support for the opposite end of the fixture. Suggested Applications: Paint spray booths, aircraft maintenance, oil drilling rigs, refineries, solvent and cleaning areas, gas processing plants, chemical manufacturing, waste treatment plants, gas processing plants.
