C1D1 Explosion Proof Enclosure - 16"X16"X8" Intl. Dims - Surface Mount - (8) 1/2" NPT (1) 1.5" NPT

LARSON ELECTRONICSSKU: PL3-EPL-AEB-16.16.8-8X0.5IN-1X1.5IN
filler

Precio:
Precio de venta$13,774.00

Descripción

Specifications / Additional Information
EPL-AEB-16.16.8-8X0.5IN-1X1.5IN Explosion Proof Enclosure Features/Ratings
Internal Dimensions: 16"L x 16"W x 8"H Class I, Divisions 1 & 2
Weight: 85 lbs Class II, Divisions 1 & 2
Wiring Hubs: (8) 1/2" NPT, (1) 1.5" NPT
Mounting: Surface Mount
Conduit: Operator Provided
  Toll Free: 1-800-369-6671
  Intl: 1-214-616-6180


*All grounding shall comply with state and local codes and meet the minimum requirements of the National Electronic Code section 250*
' Product Overview '
Made in the USA The EPL-AEB-16.16.8-8X0.5IN-1X1.5IN from Larson Electronics is an Explosion Proof Container that provides operators with a Class I and II, Divisions 1 and 2 cast aluminum enclosure designed to hold electrical equipment up to 16" by 16" by 8" in size. This enclosure features eight, 1/2" NPT and one, 1.5" NPT hubs on the enclosure. This explosion proof enclosure is ideal for indoor or outdoor applications where flammable vapors, gases, or dusts exist or stand the potential to exist. *PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO EXPLOSION PROOF ENCLOSURES* The EPL-AEB-16.16.8-8X0.5IN-1X1.5IN explosion proof enclosure is made of cast aluminum, equipped with stainless steel hinge and bolts and includes a watertight gasket for a NEMA 4X protection rating. The internal cavity of this flameproof enclosure measures 16" in length by 16" in width by 8" in height and is equipped with four surface mount mounting lugs for securing the unit. A removable backplate for easy mounting of equipment outside of the enclosure can be provided at an additional cost. Wiring hubs for completing electrical connections include the following: (8) 1/2" NPT and (1) 1.5" NPT.
