Explosion Proof Enclosure - 36"x24"x10" Internal Dimensions - C1D1 - (4) 3/4" Taps - Surface Mount

LARSON ELECTRONICSSKU: PL3-EPL-AEB-36.24.10-4X0.7WE
filler

Precio:
Precio de venta$29,161.99

Descripción

Specifications / Additional Information
EPL-AEB-36.24.10-4X0.7WE Explosion Proof Enclosure Features/Ratings
Internal Dimensions: 36€-L x 24€-W x 10€-H Class 1 Division 1 Explosion Proof
Weight: 250lbs Class 2 Division 1 Explosion Proof
Mounting: Surface Mount
Hub Size: 3/4" NPT
Hub Qty: 4 (2 West, 2 East)
  Toll Free: 1-800-369-6671

  Fax: 1-903-498-3364

*All grounding shall comply with state and local codes and meet the minimum requirements of the National Electronic Code section 250*
' Product Overview '
Made in the USA The Larson Electronics EPL-AEB-36.24.10-4X0.7WE explosion proof enclosure provides operators with a Class 1 and 2, Division 1 and 2 cast aluminum enclosure designed to hold electrical equipment up to 36" by 24" by 10" in size. Factory tapped with four 3/4" NPT holes, this explosion proof enclosure is ideal for indoor or outdoor applications where flammable vapors, gases, or dusts exist or stand the potential to exist. *PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO EXPLOSION PROOF ENCLOSURES* The EPL-AEB-36.24.10-4X0.7WE explosion proof enclosure is made of cast aluminum, is equipped with stainless steel hinge and bolts, and includes a watertight gasket for a NEMA 4X protection rating. The internal cavity of this flameproof enclosure measures 36" in length by 24" in width by 10" in height. A removable backplate for easy mounting of equipment outside of the enclosure can be provided at an additional cost. Four 3/4" NPT hubs, two on the west side and two on the east side, are factory tapped to allow conduit entry into the enclosure. Mounting is provided by four ears, two per side of the enclosure. LarsonElectronics.com can build enclosures to your specifications. If this model does not meet your needs, please contact us at 1-800-369-6671 or .
